Model NO.
4T/4000kgs
Max. Lifting Height
1900mm
Lifting Time
40s
Min Height
110mm
Weight
550kg
Over Height
2774mm
Over Width
3380mm
Cyliner Number
Double Cylinder
Width Between Columns
2490mm
Power Supply
110V/230V/400V
Document Provided
Installation and Operation Mannual
Color
Blue/Customized
Stock
Stock in China, Africa and UAE
Packing
Angle Iron Bracket
HS Code
8425429000
Production Capacity
500 Sets/Month
After-sales Service:
Local Service in Singapore, Dubai, Mozambique
Warranty:
12 Months
Lifting Capacity:
4000kgs
Double Cylinder Lift Type:
Thin Plate Type
Motor:
2.2kw
Model No.:
HS-Tp40
Manual Release Two Post Car Lift 4000KGS
Stock in Singapore, Africa and UAE
| Lifting capacity | 4000kg |
| Lifting height | 1900mm |
| Min. height | 110mm |
| Lifting time | 40s |
| Weight | 550kg |
| Motor power | 2.2kw |
| Overall height | 2774mm |
| Overall width | 3380mm |
| Width between columns | 2490mm |
| Power supply | 110V/230V/400V |
| Packing size | 2850*720*460 1Pc (Post) |
| 930 * 260 * 320 1Pc ( Pump) |
- Floor plate design is ideal choice for low ceiling shop;
- By two cylinder plate and wire rope chain balance system, lifting off and landing smooth;
- Hydraulic power unit two side device, can always adjust the rate of decline;
Manual lock release from two sides; - With 24V limit switch;
- Rubber support pad with spiral adjust the height and in stages adjust the height, optional;
- Rubber pad door-opening protection;
- Toe protection device provided;
- Have adopted 115% dynamic and 150% static loading tested;
