Model NO.
CTCH-3
Sideslip Board Dimensions (mm)
500*850
Installation Dimensions (mm)
2700*660*200
Transport Package
Metal Frame
Specification
CE
Trademark
AA4C
Origin
China
HS Code
8479899990
Production Capacity
100units/Month
AA4C auto car vehicle test line vehicle sideslip tester vehicle Inspection Station brake tester
The product description
Vehicle sideslip tester mainly used for measuring sideslip quantity caused by the car wheel camber and toe Angle, this machine is one of the important equipment of auto safety performance test.
The vehicle side slip tester is mainly used to measure the sideslip quantity caused by the joint action of the camber angle and toe angle of the vehicle, In the process of straight-line driving, the left and right movement momentum of the sideslip plate is used to measure the magnitude and direction of the wheel and judge whether the inspected vehicle is qualified. It is one of the most important equipment for automobile safety performance test. It can also assist the four-wheel aligner to detect before measurement, and judge whether the vehicle needs to adjust the four-wheel alignment, which can save vehicle maintenance time.
Strong airframe, material with high intensity, good quality. Integrated structure, dust-proof, maintenance free
High precision roller, flexible sideslip plate, initial tension in minimum level
Double sideslip plates can be selected to slide together, with synchronous error less than 0.04 mm and excellent repeatability
Double sideslip plates can be selected to slide separately, with advanced structure and simple installation
Single sideslip structure can be selected to meet various testing requirements
Instrument control or LCD control instrument with touch screen can be selected
It can be equipped with a quick reset device, which can be used for the detection of double front axle steering vehicles,
| Model | CTCH-3 | CTCH-10 | CTCH-15 |
| Maximum axle-load mass (kg) | 3000 | 10000 | 15000 |
| Applied wheel tread (width/wide) (mm) | 700(width)/2400(wide) | 700(width)/2700(wide) | 700(width)/2900(wide) |
| Detection range (m/km) | ±15 | ±15 | ±15 |
| Sideslip board dimensions (mm) | 500×850 | 1000×1000 | 1000×1100 |
| Installation dimensions (mm) | 2700×660×200 | 3000×1420×180 | 3000×1420×180 |
Vehicle sideslip tester mainly used for measuring sideslip quantity caused by the car wheel camber and toe Angle, this machine is one of the important equipment of auto safety performance test.
The vehicle side slip tester is mainly used to measure the sideslip quantity caused by the joint action of the camber angle and toe angle of the vehicle, In the process of straight-line driving, the left and right movement momentum of the sideslip plate is used to measure the magnitude and direction of the wheel and judge whether the inspected vehicle is qualified. It is one of the most important equipment for automobile safety performance test. It can also assist the four-wheel aligner to detect before measurement, and judge whether the vehicle needs to adjust the four-wheel alignment, which can save vehicle maintenance time.
Strong airframe, material with high intensity, good quality. Integrated structure, dust-proof, maintenance free
High precision roller, flexible sideslip plate, initial tension in minimum level
Double sideslip plates can be selected to slide together, with synchronous error less than 0.04 mm and excellent repeatability
Double sideslip plates can be selected to slide separately, with advanced structure and simple installation
Single sideslip structure can be selected to meet various testing requirements
Instrument control or LCD control instrument with touch screen can be selected
It can be equipped with a quick reset device, which can be used for the detection of double front axle steering vehicles,
