Model NO.
WLD-6200
Coating
Powder Coating
Airflow Direction
Fully Undershot-type
Heating Mode
Infrared Ray
Paint Mist Treatment
Dry-type
Condition
New
Model
6.9X3.9X2.6m
External Size
7000*5450*3600mm
Internal Size
6900*3900*2600mm
Air Flow
24000m3/H
Air Speed
0.3-0.5m/S
Power
37kw
Vehicle Suited
Saloon Car/Jeep/SUV
Transport Package
Export Standard
Specification
Standard Type
Trademark
WeiLongDa
Origin
Guangzhou, China
HS Code
8419899090
Production Capacity
2000 Sets/Year
After-sales Service:
Online and Others
Warranty:
12months
Type:
Spray Booth
Certification:
CE
Substrate:
EPS
Brand:
Weilongda
Configuration:
- Wallboard: Sandwich style EPS (epispastics polystyrene) 50mm thickness. Galvanized steel roof panel.
- Basement: Galvanized steel sheet and square steel pipe construction. 2 rows of grids with floor filter & 3 rows of checkered plates. 2 pcs of ramps.
- Door: 3 pcs of luxury front doors with 0.8mm thickness colorful steel skin. Size: 3000(w) x 2600(h). 1 pc of emergency door. Watching window with aluminum frame.
- Air Circulation System: 2x3kw intake fan,1x4kw exhaust fan. BELIMO 20N electric damper.
- Burner: Italy Riello G10 diesel burner, 100000Kcal/h. The heating time 7-9min(20-60.C). Max. temperature at 80.C. Fuel consumption is 4-5kg/vehicle.
- Heat Exchanger: Made of stainless steel. The heat exchange rate reaches 85%.
- Lighting System: Ceiling light has 24 pcs of 16w LED lamps. 800 Lux.
- Air Purification: Dual filtering structure. The primary filter can capture granules larger than 10μm. Ceiling filter capture granules bigger than 5μm. The air cleanliness in the working environment can reaches 98%.
- Pollution Control System: Multi-layer fiberglass filter.
