Model NO.
BZB-FB9
Heating Mode
Diesel
Paint Mist Treatment
Dry-type
Condition
New
Color
White, Red, Orange, Blue.......
Voltage
as Require
Transport Package
Polyfoam and Carton
Specification
CE ISO9001: 2000
Trademark
BZB
Origin
Guangzhou, China
HS Code
84198990
Production Capacity
500sets/Year
Type:
Spray Booth
Certification:
CE
Substrate:
Steel
Brand:
Bzb
Coating:
Painting
Airflow Direction:
Fully Undershot-type
Paint spray chamber: Producing specially designed Painting and Drying spray booths suitable for your painting work of all types of vehicles; BZB brand spray booth is with a concept of a customer-focused attitude
| industrial Spray booth | ||
| Outside size(L×W×H) | 9140×6200×4800(mm) | |
| Inside size(L×W×H) | 9000×4500×4000(mm) | |
| Cabin System | 70mm thick EPS panel;colorful steel sheet is 0.476mm thick;Ceiling panel:50mm thick EPS panel front door(W×H):3500mm×3500mm. | |
| Circulation system | Inlet fan:two sets centrifugal fan. Model:YDW-5.6M;power:7.5kw/per set; quantity:2sets | |
| Outlet fan: Model:4-82-6.3E;capacity:35128m3/h;pressure:816Pa:power:11KW:quantity;1set | ||
| air speed:0.4 m/s;air recycling times:343 time/h | ||
| Purification system | dual filtering structure,the primary can capture granules larger than 10μm,ceiling filters capture granules larger than 4μm.filtering rate 98%. | |
| Heating system | Italy Riello RG5S oil burner,260000Kcal/h,,stainless steel heating exchanger. | |
| Max temp,80 centi degree:heating times:8~12min(20~60centi degree);fuel consumption:12~25Kg/h | ||
| Lighting system | ceiling light:40 pcs 36W philips lamp.Bottom light:24 pcs 36W philips lamp. | |
| Control system | PLC Controlling, Soft Touching Button, Spray & Baking Switch, Light Switch, Emergency Stop, Breakdown Alarm | |
| Environmental system | multi-layer fiberglass filter,active-carbin. | |
| Total Power | 29.5KW | |
