Model NO.
YDC6500
Max Height
151-200mm
Certification
CE, ISO 9001:2000, SGS
Condition
New
Peoduct Name
Post Tension Hydraulic Jack
Color
Customised
Certificate
Ce an ISO
Material
Alloy Steel, Casting Iron, Steel, Plastic.
Max.Capacity
12000kn
Max.Stroke
200mm
Usage
Uildngs, Railway, Highway, and Other Prestresses C
Transport Package
Standard Export Package with Cartons
Specification
CE and ISO certificate
Trademark
Leadcrete
Origin
Henan, China(Mainland)
HS Code
84254210
Production Capacity
10000 Sets Per Month
After-sales Service:
Online support
Warranty:
2 years
Type:
Hydraulic Jack, Hydraulic Jacks
Structure:
Hydraulic Jack
Capacity (Load):
650 ton
Power Source:
Electric
YDC Prestressed concrete hydraulic jack
3. In certain circumstances it can be used in the working of pushing, jacking and transforming, and so on.
4. Easy to use at reasonable price.
5. Jack is used for prestressing works
The features of YDC Prestressed concrete hydraulic jack
YDC Feed-through jacks are the newly designed products in our company and are the upgrades of the primary jacks.
2. Using special alloy steel with heat treatment process, reducing the cylinder's expansion ratio in the tensioning process. So that the life of seals and sealing performance can be improved by about 20%.
3. In the tensioning operating process, jacks are easily damaged under overpressure because of the jack-based pullback cylinder, so we added the overpressure valve on the jacks to pressure production. Meanwhile, we improved the original commonly used structure of wire disc and flanged disc, to make the bearing capacity for oil pressure strengthen. So that enormously reduces the possibility of mechanical damage due to improper operation.
In the word, the YDC series feed-through jacks' performance is improved and widely used in pre-stressing and post-stressing construction.
Notice: According to users' requirements, YDC through jack can be configured
Please contact us for more information!
Please send an inquiry for more information!
Single acting hollow hydraulic jack/cylinder/ram (12-100 tons)
Double acting hydraulic jack/cylinder/ram (50-2000 tons)
Double acting hollow hydraulic jack/cylinder/ram (50-2000 tons)
Single acting hydraulic jack/cylinder/ram with lock nut (55-200 tons)
Thin type single acting hydraulic jack/cylinder/ram (10-200 tons)
Ultrathin hydraulic jack/cylinder/ram (10-200 tons)
Flange type hydraulic jack/cylinder/ram (10-630 tons)
Synchronous hydraulic jack (10-1000 tons)
Hydraulic accessories: high pressure oil hose, couplers, seal kits, manifold, etc.
All the tonnage, stroke, and height can be customized according to client's requirements, supplying the best quality and service. Our warranty is 2 years.
1. Usage: It is matched with prestressed anchorage widely used in the construction of bridges and buildings, railways and subways, water conservancy, and hydropower engineering.
2. It is suitable for the tension of group anchors with 1860-2000 sizes, Φ 15.24, Φ 12.7 strands.3. In certain circumstances it can be used in the working of pushing, jacking and transforming, and so on.
4. Easy to use at reasonable price.
5. Jack is used for prestressing works
The features of YDC Prestressed concrete hydraulic jack
YDC Feed-through jacks are the newly designed products in our company and are the upgrades of the primary jacks.
1. Using the new seals, to synchronously strengthen the seal-ability under great pressure.
2. Using special alloy steel with heat treatment process, reducing the cylinder's expansion ratio in the tensioning process. So that the life of seals and sealing performance can be improved by about 20%.
3. In the tensioning operating process, jacks are easily damaged under overpressure because of the jack-based pullback cylinder, so we added the overpressure valve on the jacks to pressure production. Meanwhile, we improved the original commonly used structure of wire disc and flanged disc, to make the bearing capacity for oil pressure strengthen. So that enormously reduces the possibility of mechanical damage due to improper operation.
In the word, the YDC series feed-through jacks' performance is improved and widely used in pre-stressing and post-stressing construction.
Notice: According to users' requirements, YDC through jack can be configured
| Item/Dimensions | Nominal Tension | Rated Oil Pressure | Pulling Stroke | Area of Tensioning Piston | Center hole Diameter | Minimum Working Space | The Reserved Length of Strand | Over dimension | ||
| KN | Mpa | mm | mm² | mm | L(mm) | E(mm) | K(mm) | out diameter(mm) | length(mm) | |
| YDC60 | 60 | 54 | 150 | 1119 | 30 | 874 | 59.5 | 387 | 70 | 287 |
| YDC130 | 130 | 50 | 160 | 2592 | 30 | 838 | 77 | 395 | 90 | 295 |
| YDC270 | 270 | 61 | 185 | 4418 | 30 | 888 | 89 | 415 | 105 | 315 |
| YDC650 | 650 | 50 | 150 | 13018 | 40 | 860 | 145 | 380 | 170 | 288 |
| YDC1100 | 1100 | 51 | 200 | 19792 | 80 | 1210 | 184 | 680 | 217 | 330 |
| YDC1500 | 1500 | 50 | 200 | 30257 | 90 | 1210 | 230 | 680 | 270 | 330 |
| YDC2000 | 2000 | 51 | 200 | 39820 | 110 | 1296 | 272 | 723 | 320 | 360 |
| YDC2500 | 2500 | 52 | 200 | 48381 | 127 | 1306 | 298 | 728 | 350 | 360 |
| YDC3000 | 3000 | 52 | 200 | 57727 | 145 | 1322 | 336 | 736 | 375 | 380 |
| YDC3500 | 3500 | 48 | 200 | 73435 | 162 | 1322 | 336 | 745 | 415 | 395 |
| YDC4000 | 4000 | 51 | 200 | 79168 | 162 | 1324 | 374 | 745 | 435 | 395 |
| YDC4600 | 4600 | 51 | 200 | 91028 | 180 | 1350 | 420 | 750 | 470 | 410 |
| YDC5000 | 5000 | 49 | 200 | 96997 | 200 | 1340 | 434 | 745 | 495 | 410 |
| YDC5500 | 5500 | 50 | 200 | 110506 | 198 | 1350 | 520 | 800 | 526 | 498 |
| YDC6500 | 6500 | 49 | 200 | 67544 | 212 | 1350 | 550 | 850 | 568 | 538 |
| YDC9000 | 9000 | 51 | 200 | 78618 | 275 | 1400 | 620 | 900 | 680 | 603 |
| YDC12000 | 12000 | 51 | 200 | 231300 | 275 | 1400 | 620 | 900 | 780 | 603 |
Our hydraulic jacks have been widely used in industrial fields, such as steel plants, cement industry, chemical and refinery, bridges, railways, highways, hydropower stations, ship repair, building, construction, and maintenance.
Zhengzhou Lead Equipment Co., Ltd. Has been in hydraulic tools industry since 2009. Our main products as follow:
Single acting hydraulic jack/cylinder/ram (10-100 tons)Single acting hollow hydraulic jack/cylinder/ram (12-100 tons)
Double acting hydraulic jack/cylinder/ram (50-2000 tons)
Double acting hollow hydraulic jack/cylinder/ram (50-2000 tons)
Single acting hydraulic jack/cylinder/ram with lock nut (55-200 tons)
Thin type single acting hydraulic jack/cylinder/ram (10-200 tons)
Ultrathin hydraulic jack/cylinder/ram (10-200 tons)
Flange type hydraulic jack/cylinder/ram (10-630 tons)
Synchronous hydraulic jack (10-1000 tons)
Hydraulic accessories: high pressure oil hose, couplers, seal kits, manifold, etc.
All the tonnage, stroke, and height can be customized according to client's requirements, supplying the best quality and service. Our warranty is 2 years.
