Model NO.
XNZT-001
Frequency Range
Intermediate Frequency
Electric Current
AC
Style
Vertical
Power
Servo Motor Drive
Size
5500mm *4000mm *2800mm
Transport Package
Wooden Case
Specification
6000 kg
Trademark
XiaoNeng
Origin
China
HS Code
8515809090
Production Capacity
100set/Year
Application:
Garden Supplies, Plastic Welding Machine
Cooling Way:
Air Cooling
Control:
Automatic
Plastic Pallet Hot Plate Welding Machine
Three Step:
1.Melt: Two components are softened by heating with a hot plate
2.Open: The components are removed from the heated plate after heating softening completed.
3.Seal: The components are brought together. Then subjected to pressure until the weld cools
The plastic pallet welding machine uses servo drive to make welding more accurate. Also, the
servo motor can reduce the time of welding process. The whole welding process takes about
1.2 to 1.5 minutes.
SPECIFICALLY
FAQ:
Q: Is XiaoNeng a factory or trading company?
A: XiaoNeng is a factory to produce plastic welding machine.
Q: Where is the address of XiaoNeng?
A: No.35 Yuci highway, Yuyao, Ningbo, Zhejiang, China
Q: How to visit XiaoNeng?
A: XiaoNeng is next to the Yuyao Station. You can visit us by high-speed railway.
It is need 5 mimute to our factory.
Q: What kinds of machine can produce?
A: XiaoNeng provide all kinds of plastic welding machine like HOT PLATE MACHINE,
ULTRASONIC WELDER, PLASTIC RIVETING WELDING MACHINE, PLASTIC
INDUCTUIN WELDING MACHINE and so on.
A: Also XiaoNeng provide the professional mould customization service for welding
machine. We will provide turn-key progrem.
Q: Why we choose XiaoNeng?
A: XiaoNeng make plastic welding machine for more than 10 years.We have
professional R&D to meet your customized needs. And we are constantly
updating our products. To be more automatic, to be more precise.
Three Step:
1.Melt: Two components are softened by heating with a hot plate
2.Open: The components are removed from the heated plate after heating softening completed.
3.Seal: The components are brought together. Then subjected to pressure until the weld cools
The plastic pallet welding machine uses servo drive to make welding more accurate. Also, the
servo motor can reduce the time of welding process. The whole welding process takes about
1.2 to 1.5 minutes.
SPECIFICALLY
| Product Model | XNZT-001 | Customized |
| Drive | Servo Motor + Pneumatic Drive | |
| Manual Pulse Generator | YES | |
| Voltage | 380V | |
| Move Range(up and down) | 350MM | |
| Frequency | 50/60 HZ | |
| Pneumatic Pressure | 0.5~0.8 Mpa | |
| Color | White / Yellow | |
| Pallet Thickness | 200MM | |
| Size(L W H) | 5500 X 4000 X2800MM | Customized |
| Weight | <=6000KG | Customized |
| Max Welding Length Max Welding Width | 1000MM* 1000MM 1400MM* 1400MM | |
| Pallet Shape | Shape Customized | |
| PLC | 10" Internal Touch Screen | |
| -Language | English / Chinese | |
| -Work Mold | Manual / Automatic | |
| -Control | Temperture / Time / Drive | |
| -Mold Protection | Distance Control / Heat Fusion / Heating Temperature | |
| Scope of Application | Thermoplastics(PP, PA, PE, ABS) | |
FAQ:
Q: Is XiaoNeng a factory or trading company?
A: XiaoNeng is a factory to produce plastic welding machine.
Q: Where is the address of XiaoNeng?
A: No.35 Yuci highway, Yuyao, Ningbo, Zhejiang, China
Q: How to visit XiaoNeng?
A: XiaoNeng is next to the Yuyao Station. You can visit us by high-speed railway.
It is need 5 mimute to our factory.
Q: What kinds of machine can produce?
A: XiaoNeng provide all kinds of plastic welding machine like HOT PLATE MACHINE,
ULTRASONIC WELDER, PLASTIC RIVETING WELDING MACHINE, PLASTIC
INDUCTUIN WELDING MACHINE and so on.
A: Also XiaoNeng provide the professional mould customization service for welding
machine. We will provide turn-key progrem.
Q: Why we choose XiaoNeng?
A: XiaoNeng make plastic welding machine for more than 10 years.We have
professional R&D to meet your customized needs. And we are constantly
updating our products. To be more automatic, to be more precise.
