63-160mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder, Butt Welder Machine, Plastic Butt Welder

Supplier Hangzhou Welping Machinery Equipment Co., Ltd.
Price $750.00 / Pieces
Availability In Stock
Mini Order:
+-
Subtotal: $750

Purchase details

Payments:

Tax:

Tax Included

Returns&Refunds:

Eligible for refunds within 30 days of receiving products. returns and refunds

Model NO.
WP160A
Applicable
PE, PP, PVDF
Max Temperature
270ºC
Size
63-75-90-110-125-140-160mm
Power Supply
220V 50Hz
Overall Power
3.35kw
Heating Plate
1.5kw
Planing Tool
1.1kw
Hydraulic Station
0.75kw
Pressure Adjusting
0-6.3MPa
Temperature Deviation
±5ºC
Transport Package
2PCS Plywood Case
Specification
760*460*560mm 600*460*480mm
Trademark
Welping
Origin
China
HS Code
8515809090
Production Capacity
5000pieces/Year
Welding Range:
160mm
Cooling Way:
Air Cooling
Control:
Semi-Automatic
Frequency Range:
Intermediate Frequency
Electric Current:
AC
Type:
Resistance Butt Welder

63-160mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder

ModelWP160A
Suitable materialsPE, PP, PVDF
Range63-75-90-110-125-140-160mm
Power supply220V
Frequency50 Hz
Total power3.25KW
         Heating plate1.5 KW
         Planing tool1.1KW (16A)
         Hydraulic station0.75KW
Max.Pressure6.3MPa
Hydraulic oilL-HM46
Max.Temperature of heating plate 270ºC
Temp.Deviation in Surface±7ºC
Total Weight115kg
Net weight99kg
Basic Frameplywood760*460*560mm
Hydraulic Unit & planing tool & heating plateplywood600*460*480mm
63-160mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder63-160mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder
63-160mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder63-160mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder
63-160mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder
63-160mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder
63-160mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder

63-160mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder
63-160mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder
63-160mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder
63-160mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder63-160mm Hydraulic Automatic Poly Hydraulic Butt Fusion Plastic PE Pipe Hot Melt Butt Welding Machine HDPE Pipe Welder
SNModelPipe rangePower supplyRemarks
1WP160A63-75-90-110-125-140-160 (mm)220V, 50Hz
2WP200A63-75-90-110-125-140-160-180-200(mm)220V, 50Hz
3WP250A90-110-125-140-160-180-200-225-250(mm)220V, 50Hz
4WP315A110-125-140-160-180-200-225-250-280-315 (mm)220V, 50Hz
5WP355A160-180-200-225-250-280-315-355 (mm)220V/380V,50Hz
6WP400A180-200-225-250-280-315-355-400 (mm)380V, 50Hz
7WP450A180-200-225-250-280-315-355-400-450 (mm)380V, 50Hz
8WP500A250-280-315-355-400-450-500 (mm)380V, 50Hz
9WP630A315-355-400-450-500-560-630 (mm)380V, 50Hz
10WP800A630-710-800 (mm)380V, 50Hz
11WP1000A800-900-1000 (mm)380V, 50Hz
12WP1200A1000-1100-1200(mm)380V, 50Hz
13WP1400A10001200-1400(mm)380V, 50Hz
14WP1600A1200-1400-1600 (mm)380V, 50Hzcustomized
15WP2000A1600-1800-2000(mm)380V, 50Hzcustomized
16WP2500A2200-2500 (mm)380V, 50Hzcustomized
17WP3000A3000 (mm)380V, 50Hzcustomized
