Model NO.
IPV500 / IPV 300
Welding Head
Ah-06
Max. Welding Thickness
0.35mm
Usage
Spot Welding
Weight (Kg)
23 Kg
Warranty
1 Year
Control Speed
4kHz
Transport Package
Wooden Case Package
Specification
215(W)*431(D)*274(H)
Trademark
Styler
Origin
Dongguan, China
Production Capacity
10000 Set/Year
Cooling Way:
Water Cooling
Control:
Manual
Style:
Vertical
Welding Way:
Spot Welding
Type:
Three-Phase Secondary Rectification Welder
Max Curr:
5000A
Transistor type precision energy storage spot welder
Transistor spot welding machine welding current rises very fast, can complete the welding process in a shorttime, the welding heat affected zone is small, and the welding process has no spatter. It is most suitable for
ultra-precision welding, such as thin wires, such as button battery connectors, Small contacts and metal foils
of relays
Product Paramenters
MODEL | IPV500// IPV300 |
MAX CURR | 5000A |
INPUT | Three phase 340~420VAC 50/60Hz |
CONTROLS | 1,const. curr. 2,const. volt. 3,const. curr. and volt. combination. |
pressure contact time | 0000~9999ms |
resistance pre-detection welding time | 0.00~1.00ms |
pre-detection time | 2ms(fixed) |
rising time | 2.00~49ms |
interval time | welding1,welding2 time 0.00~9.99ms |
slow down time | 2.00~49ms |
cooling time | 0.00~9.99ms |
holding time | 0.00~9.99ms |
CURR STG RG | 0.00~2.00KA |
VOLT STG RG | 0.00~9.99V |
VOLT RG | 0.00~9.99V |
EX. SIZE | 215(W)X431(H)X274(D) |
G.W. | 23KG |
