Model NO.
HDC800
Frequency Range
Intermediate Frequency
Electric Current
AC
Transport Package
Plywood Cases
Specification
1345kgs
Trademark
Huajin
Origin
China
HS Code
8515290000
Production Capacity
5000
Cooling Way:
Air Cooling
Control:
Semi-Automatic
Style:
Hot Melt
800mm Hydraulic HDPE/PE/PP Pipe Butt Fusion Welding Machine/Termofusion Welding Machine
| Model | HDC800 |
| Pipe size(mm) | 450mm,500mm,560mm,630mm,710mm,800mm |
| Heating plat Max temp | 270ºC |
| Temp deviation in surface(170-250) | ±5ºC |
| Max tolerance of welding jointing | 0.3MM |
| Max working pressure hydraulic station | 16Mpa |
| Working voltage | 380V |
| Working frequency | 50-60HZ |
| Motor power/voltage of hydraulic station | 2.2KW / 380V |
| Power/voltage of heating plate | 12.1KW / 380V |
| Power/voltage of planning tool motor | 2.2KW / 380V |
| Total Power | 15.8KW |
| Overall weight of machine(kg) | 1345KGS |
Application& Features:
1.Consist of basic frame, milling cutter, heating plate, hydraulic unit, electric unit, support.
2.Working environment must be between -40ºC~+40ºC.
3.Pressure adjustable range: 0-16Mpa.
4.Heating plate Max. temperture: 270ºC.
5.Suitable for material of PE, PP, PVDF.
