Model NO.
SUD450H
Warranty
12months
Heating Plate Max Temp
270ºC
Temp Deviation in Surface
≤±7ºC
Working Voltage
220V/380V 50/60Hz
Heating Plate Power
5.38kw
Planning Tool Power
1.5kw
Hydraulic Unit Power
1.5kw
Pressure Adjustable Rnages
0-8MPa
Certification
ISO, CE, SGS
Weight
450kg
Material
Aluminum
Application
HDPE Pipe Welding
Volume
2.2cbm
Package
3 Wooden Boxes
Transport Package
Wooden Box
Specification
2.2CBM
Trademark
SUDA
Origin
China
HS Code
85152900
Production Capacity
2000sets/Month
Welding Range:
250 280 315 355 400 450mm
Cooling Way:
Air Cooling
Control:
Semi-Automatic
Frequency Range:
Low Frequency
Electric Current:
AC
Model:
Sud450h
HDPE Butt Welding Machine/Plastic Pipe Butt Fusion Welding Machine===Brief & Feature===
Brief:
Suitable for welding of plastic pipes and fittings made from PE, PP & PVDF.
Be made of Aluminum material.
Consists of Planning Tool, Heating Plate, Basic Frame, Hydraulic Unit and Support.
Feature:
1. Removable PTFE coated heating plate with separate temperature control system.
2. Electric Planning Tool with reversible double cutting edge blades.
3. Hydraulic Unit provides welding machine with compressing power.
4. Be made of Aluminum material.
5. Low starting pressure ensures reliable welding quality of small pipes.
6. Temperature Controller and Timer, easy to know the exact time and temperature.
| Model | SUD450H | |
| Welding Range (mm) | 250 280 315 355 400 450 | |
| Heating Plate Max Temp | 270ºC | |
| Temp Deviation in Surface | ≤±7ºC | |
| Working Voltage | 220V/380V 50/60Hz | |
| Heating Plate Power | 5.38KW | |
| Planning Tool Power | 1.5KW | |
| Hydraulic Unit Power | 1.5KW | |
| Total Power | 8.38KW | |
| Pressure Adjustable Rnages | 0-8Mpa | |
| Weight | 450KG | |
| Packing | Wooden Box | 3 Wooden Boxes |
| Volume | 2.2CBM | |
===Pictures===
===Loading and Packing===
===Exhibition===
===Construction===
===FAQ===
1.The advantage for product?
High efficiency , energy saving and good quality.
2.The advantage for us ?
Reasonable price and best services , advanced equipment and strong technology.
3.How to order?
Do not hesitate to contact by online or Email as soon as possible once you are interested in our products. The specific quotation will be offered basing the request dimension and quantity
4. What about the quality?
All products according to ISO and National highest standard, also we can offer CE, certificate if necessary. The machine have one year warranty.
5. What payment is available?
T/T, L/C,Westion Union
===Why Choose Us===
1)Genuine products with excellent quality and competitive price.
2)Cooperating with the customer all over the world and knowing the markets very well.
3)After-Services will be highly-satisfied. Any problems and feedbacks will be answered in a short of time.
4)Why our price very stable and competitive?
5)Our factory have ourselves meltshop, most parts of the body machines from ourselves factory, save the cost.
6)We have some big customers from Southeast Asia Market and Russia Market, every mouth have the stable machines export, keep our value of exports
