Model NO.
CKD-WLA-200
Conductive Way
One-Sided
Welding Spot Number
Single
Type
Special
Warranty
12 Monthes
Shipping Date
3-5 Work Days After Payment
Cooling Model
Water Cooling
Attachments
Water Chiller and Foot-Switch
Transport Package
Wooden Box
Specification
185Kg, net weight with water chiller
Trademark
CKD LASER
Origin
Shenzhen, China
HS Code
8515809090
Production Capacity
200 Sets/Month
Control:
Semi-Automatic
Cooling Way:
Water Cooling
Style:
Hanging
Electrode Stroke:
Vertical
Electric Current:
Capacitor Energy Storage
Transmission:
Pedal
APPLICATION
INDUSTRY:
Precision welding on various tiny parts, for example, jewelry, electronics, communication, precision metails, watches and also can be used to fill blister of false tooth, etc.
MATERIAL:
Gold, silver, titanium, stainless steel, copper, aluminum and so on.
TECH PARAMETERS
| Parameter | Unit | Data |
| Type | CKD-WLA-200 | |
| Laser power | W | 200 |
| Working medium | Nd:YAG | |
| Central Wavelength | nm | 1064 |
| Pulse frequency | Hz | 1-40 |
| Pulse width | ms | 0.1-20 |
| Electricity | A | 60-300 |
| Min. output power | W | 10 |
| Single pulse energy | J | 80 |
| Ocular multiple | times | 10 |
| Cooling mold | Water cooling | |
| Water chiller | Outside | |
| Power Source Requirement | 90-240V/50-60Hz/2KVA | |
| Working temperature | ºC | 25±2 |
| Dimension | mm | 1010*550*1220 (machine) |
| 700*360*590 (includes the size of filter vat) | ||
| Weight | Kg | 185 (with outside water chiller) |
OPTIONAL STANDBY PARTS OF CONSUMPTIONS
ADVANTAGES
* Precision weld without surface touch.
* Small heat-affected zone.
* Data adjustable and easy operation.
* Professional desingn, convenient to metal recycle.
* Helthy, use adcantaced automatic light shielding system, eliminating light stimulating to eyes.
* 10X microscope magnification, cross cursor indicating, the shielding gas output in synchronization with the laser, assure good appearance of solder joint.
PACKIGN&SHIPPNG
SAFETY PROTECTIVE INNERPACKING AND OUTER PACKING
SEPARATELY SAFTY PACKING TO SAVE YOUR SHIPPING CHARGE
