Model NO.
WP630B
Hydraulic Station
Enclosed
Warranty
18 Months
Package Quantity
3 PCS
Transport Package
Plywood
Specification
Hydraulic drive
Trademark
Welping
Origin
China
HS Code
8515809090
Production Capacity
20000 Pieces/Year
Welding Range:
315-630mm
Cooling Way:
Air Cooling
Control:
Semi-Automatic
Frequency Range:
Low Frequency
Electric Current:
AC
Type:
Resistance Butt Welder
| Model | WP630B | |
| Suitable materials | PE,PP,PVDF | |
| Range | 315-630mm | |
| Power supply | 380V | |
| Frequency | 50HZ,60HZ is optional | |
| Total power | 10.1KW | |
| Heating plate | 7.5KW | |
| Planing tool | 1.5KW | |
| Hydraulic station | 1.1KW | |
| Max.Pressure | 8Mpa | |
| Hydraulic oil | L-HM46 | |
| Max.Temperature of heating plate | 270ºC | |
| Temp.Deviation in Surface | ±7ºC | |
| Basic Frame | Plywood | 1540*930*990mm |
| Hydraulic Unit | Plywood | 680*530*730mm |
| Planing tool heating plate | Plywood | 750*620*1260mm |
| Total Weight | G.W | 565KGS |
| SN | Model | Pipe range | Power supply | Remarks |
| 1 | WP110B | 40-50-63-75-90-110 (mm) | 220V, 50Hz | |
| 2 | WP160B | 63-75-90-110-125-140-160 (mm) | 220V, 50Hz | |
| 3 | WP200B | 63-75-90-110-125-140-160-180-200 (mm) | 220V, 50Hz | |
| 4 | WP250B | 90-110-125-140-160-180-200-225-250 (mm) | 220V, 50Hz | |
| 5 | WP315B | 110-125-140-160-180-200-225-250-280-315 (mm) | 220V, 50Hz | |
| 6 | WP355B | 160-180-200-225-250-280-315-355 (mm) | 220V/380V, 50Hz | |
| 7 | WP400B | 160-180-200-225-250-280-315-355-400 (mm) | 380V, 50Hz | |
| 8 | WP450B | 200-225-250-280-315-355-400-450 (mm) | 380V, 50Hz | |
| 9 | WP500B | 250-280-315-355-400-450-500 (mm) | 380V, 50Hz | |
| 10 | WP630B | 315-355-400-450-500-560-630 (mm) | 380V, 50Hz | |
| 11 | WP800B | 630-710-800 (mm) | 380V, 50Hz | |
| 12 | WP1000B | 800-900-1000 (mm) | 380V, 50Hz | |
| 13 | WP1200B | 1000-1100-1200(mm) | 380V, 50Hz | |
| 14 | WP1600B | 1200-1400-1600 (mm) | 380V, 50Hz | customized |
| 15 | WP2000B | 1600-1800-2000(mm) | 380V, 50Hz | customized |
| 16 | WP2500B | 2200-2500 (mm) | 380V, 50Hz | customized |
| 17 | WP3000B | 3000 (mm) | 380V, 50Hz | customized |
Basic Frame:
Featured by
· Italy DNP quick coupler
· Chromated hydraulic cylinder made
of 1045(ASTM)/S45(JIS)/C45(DIN) steel
· Chromated integral shaft made
of1045(ASTM)/S45C(JIS)/C45(DIN) steel
· Base made of Q235 steel with spraying treatment
· Cast aluminum clamps, sandblasting & Spraying
treatment
Featured by
· Italy DNP quick coupler
· Chromated hydraulic cylinder made
of 1045(ASTM)/S45(JIS)/C45(DIN) steel
· Chromated integral shaft made
of1045(ASTM)/S45C(JIS)/C45(DIN) steel
· Base made of Q235 steel with spraying treatment
· Cast aluminum clamps, sandblasting & Spraying
treatment
Planing Tool
- Featured by
- HSS blade with double edge
- Die-cast aluminum trimmer plate, durable and anti-corrosion
- Aluminum alloy frame of motor with good heat dissipation performance
- Carbon brush motor with pure copper wire
Hydraulic station
Featured by
Featured by
- Integrated LCD display and control
- 220V asynchronous motor
- CHNT electricity leadkage protection switch
- Ø100mm presure meter
- Relief valve, regulating valve, maintaining valve
Heating Plate
Featured by
Featured by
- Bakelite handle with high insulating property and thermal insulation
- Thermocouple temperature sensor
- Heating element
- Teflon Coating imported from Daikin in Japan
- Aviation plug
