Swing Type T Plate Welding Tractor for Double Side Welding
1.Features:
(1)Which is suitable for continuous horizontal fillet welding structure is double side welding device.
(2)This carriage is small in size, light in weight.
(3)This carriage is convenient for moving and installing.
2.Advantages:
(1)Reduce labor intensity and improve operating environment.
(2)Improved work efficiency, 1.5 times that of manual welding.
(3)Zero welding defect rate and nearly 200% improvement in overall efficiency over manual welding.
(4)High automation, high welding stability.
3.Outside drawing
(1)Drive part: It is a device to drive the carriage, constituted by two sets of magnetic wheels, transmission gears, and the drive motor. Due to large magnetic wheel suction, they can firmly adsorb on steel plate, to ensure that the carriage will not change its walking path.
(2)Guide wheel: the carriage starts, because the carriage's own weight focus on the two guide wheels, guide wheels guide the carriage to run along the steel plate end face.
(3)Electrical box: the machine's electrical components are installed in it, at the same time to ensure that the electrical components are not affected by dust.
(4)Control panel: It can adjust all actions of carriage. Please refer to "explanation of control panel".
(5)Welding gun cable clamp: a device to fix the welding gun cable, for the convenience of welding gun, the screw type cable clip is adopted.
(6)Portable handle: it is convenient for the machine to be transited and carried.
(7)Lifting lever: it is connected with the welding gun holder, through its lifting movement, can adjust the height of welding gun, to ensure that the gun and seam are in the best position.
(8)Transverse bracket seat: can adjust two welding guns left side and right side distance.
(9)Mobile lifting seat: adjust the welding guns up and down distance.
(10)Angle adjustment device: can fine-tune the angle of welding gun and seam.
(11)Work piece.
(12)The Gun: the Keep the gun or curved gun, the customer make choice of purchase.
Workshop
Quality control
Warehouse
Q1: How many MOQ?
A: MOQ= 1set
Q2: How about the Lead time?
A: For general parameter products,we can dispatch within 1-3 days after order confirmed.
Q3: Who take charge transportation fee?
A: Our price is FOB,exclude transportation fee,but we can quote it based on your order,you can choose.
Q4: Do you offer the guarantee for your products?
A:Yes, we offer 12 months warranty for our products.
Q5: What certificates can you support?
A: Explosion-proof CNEX,ISO9001, CE and ATEX.
Q6:Is it ok to print my logo on the gas detector?
A: Yes, OEM and ODE are available.
Q7:Can I get some discount?
A: Different products have different discount,please contact us for details.
Q8: Can I pay by T/T?
A: Yes,you can,T/T and Paypal are supported.
Q9: Do you have after sales technical guidance?
A:Yes,any questions you can show us and our technical team will service for you at any time.
Welcome to write down your requirements and more questions in the below column and Click "Send" for more information,thank you.
