Model NO.
MIG-200
Frequency Range
High Frequency
Electric Current
Inverter
Color
Red
Type
MIG Welders
Current
Direct Current
Application
Ship
Model
MIG/TIG/MMA
Transport Package
Carton
Specification
CE, SGS, ISO9001
Trademark
SHSY, SANYU
Origin
Shanghai
HS Code
85153900
Production Capacity
4000PCS Per Week
Cooling Way:
Air Cooling
Shielding Gas:
Carbon Dioxide
Control:
Manual
| 1. MIG SERIES soldadora mig uses Mix gas as shielded gas to realize gas shielded welding, active gas(Ar+O2,Ar+CO2) as shielded gas to realize MAG welding and inactive gas(Ar)as shielded gas to realize MIG welding | ||||
| 2.Easy-to-underdstand operator interface.Select material type,set wire diameter then start welding | ||||
| 3.Digital control system, real-time display the welding parameters;digital voltmeter and ammeters for easy viewing | ||||
| 4.Stick with adjustable Arc force;Wave form control;stable welding arc | ||||
| 5.Lift TIG with solenoid valve and adjustable down slope time | ||||
| 6.Thermal overload,over voltage and over current protection automatically shuts down the power source to prevent high repair cost | ||||
| 7.Synergic control of the welding current and voltage | ||||
| 8.5kg spool size makes machine light and portable | ||||
| 9.Flux cored self-shielded |
3. Specification of Home application TIG/MIG/MMA Inverter soldadora mig
| Item/Model | MIG-200 | MIG-160 | ||||
| Voltage | 220V+/-15% | 220V+/-15% | ||||
| Frequency | 50/60HZ | 50/60HZ | ||||
| Rated Input Power | MIG | TIG | MMA | MIG | TIG | MMA |
| 5.9KW | 4.3KW | 5.5KW | 4.2KW | 3.2KW | 5.1KW | |
| Rated Input Current | 37A | 27.4A | 36A | 27A | 20A | 31.6A |
| Output Current Range | 25-200A | 10-200A | 10-170A | 25-160A | 10-160A | 10-160A |
| Duty Cycle at 40°C | 30% | 30% | ||||
| No Load Voltage | 58V | 58V | ||||
| Welding Voltage Range | 15V-24V | 10.4V-18V | 20.4V-26.8V | 15V-22V | 10.4V-16.4V | 20.4V-26.4V |
| Efficiency | 85% | 85% | ||||
| Power Factor | 0.72 | 0.72 | ||||
| Wire Diameter | SS:0.8/0.9/1.0MM;/1.0MM | Fe:0.6/0.8/0.9/1.0MM | ||||
| Net Weight | 13.5kgs | 11.5kgs | ||||
| Dimension | 470*210*380MM | 470*210*380MM | ||||
| IP | 23S | 23S | ||||
| Insulation Class | F | F | ||||
| Cooling | Air | Air | ||||
Shanghai Sanyu is one of the leading AC drive, Power Saving VFD, soft starter and welding machine manufactures
and exporters in Shanghai China, which has about twenty years history in this field.
Till now our products have been exported to more than 30 countries.
Our inverter and soft starter were used in "Beijing Center, Shanghai Expo Pavilion, Shanghai Air Port" etc.
And we have CE, ISO9001, SGS, CCC certificate and so on.
