Model NO.
140 ECO LUNA
Non-Load Voltage
60V
Output Current Range
20-140A
Rate Duty Cycle
60%
Rate Input Voltage
220V
Efficiency
85%
Electrode Max.
3.2mm
N.W/G.W
3.5kg/5.5kg
Transport Package
Brown Carton Box
Specification
350*125*225mm
Trademark
fengbao
Origin
China
HS Code
8515390000
Production Capacity
5000pieces/Year
Cooling Way:
Air Cooling
Style:
Portable
Frequency Range:
50/60Hz
Electric Current:
DC
Work Form:
One-Body
Type:
Manual Metal-Arc Welder
*** IMPORTANT NOTICE ***
Kinly note that we supply different appearance of ECO MMA welders for your option.The price among them is some
different according to your selection, please consult us for more information.
different according to your selection, please consult us for more information.
| Model | MMA-140ECO LUNA |
| inverter Type | IGBT |
| Rated input Voltage(V) | 220V |
| Rated input Power(KVA) | 4.5kw |
| Rated input frequency(HZ) | 50HZ |
| Non-load Voltage(V) | 60V |
| Output current MAX.(A) | 140A |
| Rated Duty cyle(%) | 60% |
| Efficiency(%) | 85% |
| Class of Insulation | F |
| Shell protection grade | IP21S |
| Suggested Electrode Max | 3.2mm |
| Connector size | 9mm |
| N.W./G.W.(kg) | 3.5kg/5.5kg |
| Machine Size(LxWxH mm) | 350*150*225mm |
| Packaging | BROWN CARTON BOX |
| Dimnsions(WXDXH mm) | 430*180*290mm |
Certificate
Exhibition
FAQ
1. Who are we?
We are the professional manufacturer of welding machines and plasma cutters since 2011.
We're located at Wenling City of Zhejiang Province in maindland of China.
2. What do we manufactur?
We're mianly producing Inverter Welding Machine of
We're mianly producing Inverter Welding Machine of
MMA welders from 100 Amp to 500Amp (DIY or Industry purpose).
TIG welders from 160Amp to 300Amp, (DC or AC/DC).
MIG/MAG welders from 120Amp to 230A, (Gas or Gasless).
Air Plasma Cutter from 40Amp to 120Amp, (Pilot or HF arc strike).
3. How can we guarantee the quality?
Always a pre-production sample before mass production;
Always 100% final Inspection before shipment.
4. What is your warranty terms?
We provide 1 year warranty time for the whole machine since you received it.
We provide 1 year warranty time for the whole machine since you received it.
During the time, we will supply you the free spare parts for maintanence.
Meanwhile, we offer on-line technical supports for operating guide and troubleshooting.
5. What we can do?
OEM/ODM is available.
Small order is acceptable, even 1 piece.
Quick Delivery is available in 45 days.
Overseas Warehouse (Russia & West-Europe) supports Fast dispatch.
