Welcome to visit our showroom! It's my honor to introduce you our product.
This TIG400MIJ welding machine is standards Riland type machine. Riland company invented this Mosfet Technology inverter welding machine at the year of 1987. After continuously updating, the Mosfet inverter welding machine become very mature and very stable. We sincerely obey Riland original design because our experienced engineer, more than 15 years in this area, think that Riland design is very mature, and any change of the design may caused machine problem. A lot of other factory tried. we saw many examples.
TIG/ARC SERIES IGBT INVERTER PULSE ARGON ARC/HAND ARC MULTIPLE FUNCTION WELDING POWER RESOURCE
TIG/ARC-400MIJ
DC pulse argon arc welding, DC argon arc welding, DC ARC welding three functions
Performance characteristics:
*The digitization control circuit, full functions and regulate easily.
*DC pulse argon arc welding, DC argon arc welding, DC ARC welding three functions.
*Mainly use for the welding of stainless steel, mild steel, high-strength steel, copper and the other alloys materials.
*Applicate extensively with aerospace, locomotive, ship, press container, petrochemical, motorbike, bicycle, hydropower, steel wood furniture fields and so on.
*Digitization inverter technology, greatly improve the whole machine's performance and reliability.
* Welding control exact, high arcing success rate.
*Intuitive and clear digital display.
*Self-lock or not self-lock functions.
*Overheat or lack voltage automatic protective functions.
*Excellent MMA function.
Specification:
| Type | WSM 400 | |
| control mode | IGBT inverter | |
| Rated input voltage | AC380V | |
| Rated input capacity(KVA) | 18.4 | |
| Cable cross-sectional area | mains input(mm2) | 6 |
| power output(mm2) | 50 | |
| ground wire(mm2) | 4 | |
| Duty cycle(%) | 60 | |
| Rated output no-load voltage(V) | 72 | |
| Output current adjustment range(A) | 5-400 | |
| Starting current adjustment range(A) | 10-160 | |
| Pulse frequency(HZ) | 0.2-50 | |
| Arc ignition mode | High frequency arc striking | |
| Enclosure rating | IP21S | |
| Insulation rating | F | |
| Cooling method | Air | |
| Power factor | 0.93 | |
| Dimensions(mm) | 560*290*530 | |
| Host weight(KG) | 25 | |
