Model NO.
ARC200
Model Number
Arc200gh or as Your Demands
Main Technology
IGBT Inverter Technology
Real Max Current(a)
180
Package
Plain or Colorful Carton
Dimention of Carton(mm)
440*260*340
Rod Can Be Used(mm)
2.5/3.2
Workpiece Thickness(mm)
2.0-8.0
Base Material
Carbon Steel, Stainless Steel, Low-Alloy Steel
Current
Direct Current
Model
Arc200
Transport Package
Standards Sea Carton or Customized
Specification
CE
Trademark
N/M
Origin
Shenzhen, Guangdong China
HS Code
8515319900
Production Capacity
as Order
Cooling Way:
Air Cooling
Style:
Portable
Frequency Range:
High Frequency
Electric Current:
DC
Work Form:
One-Body
Type:
Manual Metal-Arc Welder
AC 220V Arc200 DC Inverter Portable Welder
Features:
1. Outstanding Arc Stability with Low Spatter.
2. Auto Protection against Over-Voltage and Over-Current.
3. Wide Range for Input Voltage:220V±15%
4. Super Portable and Energy Saving.
Parameters:
| Product Model | ARC200 |
| Input Voltage | 220V±15% |
| Rate Input Voltage | 27.2V |
| Rated Input Current | 27.8A |
| No-load Voltage | 60V |
| Output Current Range | 20-180A |
| Rated Duty Cycle | 60% |
| Efficiency(η) | 0.8 |
| Insulation Grade | F |
| Protection Grade | IP21S |
| Dimension(L*W*H mm) | 371*153*250 |
| Net Weight | 6.5KG |
| Color | Red, Blue, Gray, other customized colors |
