Model NO.
SUD200M2
Fusion Range(mm)
40 50 63 75 90 110 125 140 160 180 200
Power
1.6kw/220V
Certification
ISO, Ce
Warranty
14 Months
Weight
45kg
Material
Aluminum
Current
Alternating Current
Model
Sud200m2
Application
Butt Fusion Welding Machine for Polyethylene Pipe
Volume
0.15cbm
Transport Package
Wooden Box
Specification
ISO, CE
Trademark
SUDA
Origin
China
HS Code
8515290000
Production Capacity
2000 Sets/Year
Welding Range:
200mm
Cooling Way:
Air Cooling
Control:
Manual
Frequency Range:
Low Frequency
Electric Current:
AC
Type:
Resistance Butt Welder
Butt Fusion Welding Machine for polyethylene pipe
Application & Features
1. Consist of Basic frame, Hydraulic unit, Trimmer, Heater, and Electric Control Unit
2. Removable PTFE coated heating plate with separate temperature control system.
3. Electric Trimmer with reversible double cutting edge blades.
4. Hydraulic unit provides welding machine with compressing power.
5. Be made of Aluminum material, easy to carry and transport.
6. Low starting pressure ensures reliable welding quality of small pipes.
7. Temperature Controller and Timer, easy to know the time and temperature.
Specification Data:
Our advantages
1.The main accessories of the welding machine are made by fully automatic aluminum casting. It is lighter, more solid and smooth than the machine made by sand-casting and steel-form technology.
2.Using static plastic-spraying process, colorful,smooth surface and not easy to be damaged.
3.The main accessories of the hydraulic station are imported overseas, which could reduces the maintence and extends the life of hydraulic station.
4.The package we use is fumigated cartons which has nice appearance and solid structure for convenient trasportation.
Service
1. One year warranty, life-long maintenance.
2. In warranty time, if non-artificial reason damaged can take old change new for free. Out of warranty time, we can Offer maintenance service (charge for material cost).
FAQ
1. Payment terms:
The buyers pay the total amount payment before delivery by T/T
2. Delivery time:
The delivery time shall be in 3days after the seller receives the payment
3. Packing condition:
To be informed after final packing finished
4. Warranty:
The warranty period is 14 months after testing successfully in customer's factory, but not exceeds fourteen months after delivery
Welcome to inquiry anyone welding machine !
Suda Plastic Pipe Machinery Co., Ltd.
Ms. Jenny
Tel:0086-532-66569182
Cellphone: 0086 15064878065
Website: http://findtextile.com/store/sudabuttfusionwelder
http://www.findtextile.com/store/sudabuttfusion
Application & Features
1. Consist of Basic frame, Hydraulic unit, Trimmer, Heater, and Electric Control Unit
2. Removable PTFE coated heating plate with separate temperature control system.
3. Electric Trimmer with reversible double cutting edge blades.
4. Hydraulic unit provides welding machine with compressing power.
5. Be made of Aluminum material, easy to carry and transport.
6. Low starting pressure ensures reliable welding quality of small pipes.
7. Temperature Controller and Timer, easy to know the time and temperature.
Specification Data:
| Model | SUD160M-2 | SUD200M-2 | SUD250M-2 | |
| Welding Range(mm) | 40 50 63 75 90 110 125 140 160 | 40 50 63 75 90 110 125 140 160 180 200 | 63 75 90 110 125 140 160 180 200 225 250 | |
| Heating Plate Max. Temp. | 270ºC | |||
| Temp. Deviation in Surface | ≤±5ºC | |||
| Working Voltage | 220V,50HZ | |||
| Heating Plate Power | 1.0KW | 1.60KW | 2.0KW | |
| Planning Tool Power | 0.71KW | 0.71KW | 0.83KW | |
| Total Power | 1.71KW | 2.31KW | 2.83KW | |
| Pressure Adjustable Ranges | 0-6.3Mpa | |||
| Weight | 44kg | 45kg | 70kg | |
| Volume | 0.15CBM | 0.15CBM | 0.20CBM | |
1.The main accessories of the welding machine are made by fully automatic aluminum casting. It is lighter, more solid and smooth than the machine made by sand-casting and steel-form technology.
2.Using static plastic-spraying process, colorful,smooth surface and not easy to be damaged.
3.The main accessories of the hydraulic station are imported overseas, which could reduces the maintence and extends the life of hydraulic station.
4.The package we use is fumigated cartons which has nice appearance and solid structure for convenient trasportation.
Service
1. One year warranty, life-long maintenance.
2. In warranty time, if non-artificial reason damaged can take old change new for free. Out of warranty time, we can Offer maintenance service (charge for material cost).
FAQ
1. Payment terms:
The buyers pay the total amount payment before delivery by T/T
2. Delivery time:
The delivery time shall be in 3days after the seller receives the payment
3. Packing condition:
To be informed after final packing finished
4. Warranty:
The warranty period is 14 months after testing successfully in customer's factory, but not exceeds fourteen months after delivery
Welcome to inquiry anyone welding machine !
