Model NO.
SDE315B
Frequency Range
Intermediate Frequency
Electric Current
AC
Weld Range
20-315mm
Input Voltage
AC170-250
Frequency
50Hz
Output Power
3.5kw
Weight
20kg
Type
Tube Welders
Current
Alternating Current
Model
Sde315
Application
HDPE Tube Welding
Voltage
220V
Transport Package
Standard Export Wooden Box
Specification
ISO, CE, SGS
Trademark
SDE
Origin
China
HS Code
85152900
Production Capacity
10000sets/Year
Cooling Way:
Air Cooling
Control:
Automatic
Style:
Portable
Welding Electrofusion Machine 20-315mm
=====>>Product Description
Electrofusion welding machine is suitable for connecting PE pipes and fittingswith coupling which are used for gas and water supply
=====>> Features
1.Design and according to ISO12176 electro-fusion welder international standard.
2.High lever MCU is used as control core, equipped with LCD display, all welding parameters could be displayed.
3.Light weight, easy operation.
4.By real-time monitoring weld status, abnormal welding process could be terminated in short time.
5.Built in memory, can record more than 500 welding records.
6.Welding records could be download to USB flash disk via USB interface.(Optional Function)
7.Welding wiring is easy and simple to avoid wiring error.
8.Welding parameters input modes:(1)Manually Set;(2) Read in by bar code scanner.
=====>>Specification
=====>>More Pictures
1. The shell of 1000mm electrofusion welding machine extension is water-proof.
2. Our welding heads are adjustable, that means whatever your fittings is 4.0, 4.7, 5.0mm, in our machine, only need one welding heads can finish welding.
3. The power cable is thicker and the machine is stable.
4.Machine internal overview
5. Language
Our Electrofusion machines with Chinese,English,Spanish, Russia and Polish operate Language, you can select according to your inquiry.
=====>>Packing
=====>>More Choice
=====>>Contact Us
=====>>Product Description
Electrofusion welding machine is suitable for connecting PE pipes and fittingswith coupling which are used for gas and water supply
=====>> Features
1.Design and according to ISO12176 electro-fusion welder international standard.
2.High lever MCU is used as control core, equipped with LCD display, all welding parameters could be displayed.
3.Light weight, easy operation.
4.By real-time monitoring weld status, abnormal welding process could be terminated in short time.
5.Built in memory, can record more than 500 welding records.
6.Welding records could be download to USB flash disk via USB interface.(Optional Function)
7.Welding wiring is easy and simple to avoid wiring error.
8.Welding parameters input modes:(1)Manually Set;(2) Read in by bar code scanner.
=====>>Specification
| MACHINE SPECIFICATION | ||||
| Model | SDE315B | SDE500B | SDE630B | SDE1000B |
| Welding Range(mm) | 20-315mm | 20-500mm | 20-630mm | 20-1000mm |
| Input Voltage(V) | AC220±20% Frequency 40-65HZ | AC380±20% Frequency 40-65HZ | ||
| Output Power(KW) | 3.5KW | 12.0KW | 15.0KW | 18.0KW |
| Output Voltage(V) | 120V | 170V | 210V | 210V |
| Dimension | 467X204X335mm | 467x204x335mm | 515x204x386mm | 515x204x386mm |
| Data Record Quantities | 500 | 500 | 500 | 500 |
| Working Time | It can work 24 hours constantly | |||
| Working Model | Constant voltage,Constant Current | |||
=====>>More Pictures
1. The shell of 1000mm electrofusion welding machine extension is water-proof.
2. Our welding heads are adjustable, that means whatever your fittings is 4.0, 4.7, 5.0mm, in our machine, only need one welding heads can finish welding.
3. The power cable is thicker and the machine is stable.
4.Machine internal overview
5. Language
Our Electrofusion machines with Chinese,English,Spanish, Russia and Polish operate Language, you can select according to your inquiry.
