Model NO.
SUD160H
Warranty
14 Month
Working Voltage
220V 50Hz
Certification
Ce,ISO,SGS
Total Power
3.35kw
Heating Plate Power
1.5kw
Plannimg Tool Power
1.1kw
Hydraulic Unit Power
0.75kw
Weight
120kg
Volume
0.5cbm
Package
2 Wooden Boxes
Uasge
HDPE Pipe / Fitting Welding
Material
Aluminum
Suitable for Welding Material
PE, PP, PVDF
Color
Customized
Pressure Adjustable Ranges
0-6.3MPa
Transport Package
Wooden Box or Plastic Film
Specification
SUD160H
Trademark
SUDA
Origin
China(Mainland)
HS Code
85152900
Production Capacity
1000sets/Months
Welding Range:
40mm-160mm
Cooling Way:
Air Cooling
Control:
Semi-Automatic
Frequency Range:
Low Frequency
Electric Current:
AC
Type:
HDPE Butt Welding Machine
40-160mm HDPE Butt Welding Machine/Butt Fusion Jointing Machine
Construction Site
Some Advantages
1. Suitable for welding of plastic pipes and fittings made from PE, PP&PVDF.
2. Be made of Aluminum material.
3. Consists of Planning Tool, Heating Plate, Basic Frame, Hydraulic Unit and Support.
4. Removerable PTFE coated heating plate with seperate temperature control system.
5. Electric Planning Tool with reversible double cutting edge blades.
6. Hydraulic Unit provides welding machine with compressing power.
7. Low starting pressure ensures reliable welding quality of small pipes.
8.Temperature Controller and Timer, easy to know the exact time and temperature
Specification
| Model | SUD160H |
| Welding Range(mm) | 40 50 63 75 90 110 125 140 160 |
| Heating Plate Max. Temp | 270°C |
| Temp. Deviation in Surface | ≤±5°C |
| Working Voltage | 220V/50HZ |
| Heating Plate Power | 1.50KW |
| Planning Tool Power | 1.10KW |
| Hydraulic Unit Power | 0.75KW |
| Pressure Adjustable Ranges | 0-6.3MPa |
| Total Power | 3.35KW |
| Weight | 180KG |
| Volume | 0.50M3 |
