LUCKIN VEHICLE supply 3/4 Axles 3 Axles Fence Stake Bulk Cargo Semi Trailer, which has a pallet structure and wide range of uses. It is mainly suitable for medium and long-distance transportation of medium, heavy and bulk goods, such as grain, bagged cement, agricultural products, ect.
The trailer's side panels can be opened for easier unloading and the shape of the side panels can be customized. Drop Side Semi Trailer has become the first choice for medium and long-distance freight vehicles based on its strong applicability, and it becomes the first choice for medium and long-distance freight vehicle for a lot of transport companies in the logistics industry.
Besides, all accessories and configuration adopt international famous brand parts, which makes our trailers not only increase long service life, but also improve operating efficiency and save maintenance costs.
| Model | QLV9350LTP | |
| Overall length | 12500mm | |
| Overall width | 2550mm | |
| Overall Height | 2700mm | |
| Specifications | ||
| Item | Qty. | Notice |
| Main Beam | Height 500mm; Heavy duty and extra durability designed I beam;Opting for high tensile steel Q345B, welded by automatic Submerged-Arc processes.Top and bottom palte width 140mm. | |
| "I" shape Top plate 14mm; Bottom plate 16mm, Middle plate 8mm | ||
| Platform | 3mm thickness checkered plate | |
| Landing gear | 1 | 28T, JOST |
| Kingpin | 1 | 2.0/3.5 inches, JOST |
| Axle | 3 | FUWA/BPW/ZY, or other brands |
| Tyre | 12 | 12R22.5/11R22.5/12.00R20/11.00R22.5/315/80R22.5 |
| Rim | 12 | 9.0-22.5/8.5-20 |
| Leaf spring | 6 | 10pieces 90mm width*13mm thickness |
| Suspention | 3 | American type |
| Braking system | 2 line air braking system with air tank ,emergency relay valve WABCO,braking chambers and mechanical slack adjusters.Domestic ABS 4S/2M | |
| Electrical system | 24 volt electrical system.7 pin electrical connector.Parking .Stop,reverse,number plate and indicator lights.Rear lights conform to European standard,rear front and side reflectors | |
| Shotblasting and paint | Chassis is comletely shotblasted to SA 2.5 grade,and painted with first layer of international Zinc Epoxy primer(30 Microns DEF),second layer international high built polyurethane under coat(40 microns DFT),THIRD AND FORTH LAYERS INTERNATIONAL alkyd FINISH TOP coat.Total 80-100 microns.Waxed | |
1.Mature Welding Process: LUCKIN VEHCLE adopts automatic submerged arc welding method to weld the main beam. The longitudinal beam is completed by automatic tracking submerged arc welding machine. All components are shot peening to improve paint adhesion and are painted prior to assembly, making the main beam stronger and more durable.
2. Reliable Materials: We adopts high strength steel material to manufacture the flatbed trailer, it can make the flatbed trailer have a higher loading capacity and a longer service life. Besides, all the main parts, used in our trailers, must be processed with advanced equipment and have good reputations in the market.
3. Mature Design and Manufacture: We would like to design the trailer according to our customers' needs and special using conditions. Also, we would consider more than what them based on their final usage, and provide customers with reasonable suggestions when they are hesitating.
4. Rich Exporting Experience: More than 20 years of experiences in producing and exporting trailers and other goods, we have helped hundreds of customers in more than 35 countries in Africa and Southeast Asia.
5. Quality Assurance:We would offer 2 years' warranty for chassis frames of our trailers and also be responsible for the damage of parts during normal use.
6. Customized Service: We support customized designing and production according to customers' different needs and different road situations to match your usage in local.
1. Who are we?
Answer: LUCKIN VEHICLE is a group company; we have three trailer factories in Shandong and one trading company in Qingdao. We are focus on semi-trailers, trucks and parts.
2. Why choose us
Answer: 1) We have more than 20years experience in the trailer manufacturing. LUCKIN VEHICLE has got high reputations in China and oversea countries.
2) We have more than 20 engineers to design the kinds of trailers according to the detailed requirements and needs from customers.
3) We had exported thousands of trailers to Africa, Middle East, Asia, Australia, South America since 2005.
3.How long does it usually take to receive the goods?
Answer:It usually takes 30 to 40 days of receiving the deposit.
4.Payment and mode of transportation?
Answer:We accept both T/T and D/P .
Bulk, rolling, loading, container transportation, I will actively provide customers with cheaper transportation.
5. If Our Trailer Can Couple With Your Tractor Head ?
Answer:- 90% Of The Truck In The Market Can Coupling With Our Vehicle, As Howo, Shacman...
- If Other Brand Truck Head, Please Inform Our Sales Manager Before Order Placing.
6.Can you satisfy my special requirement?
Answer:Definitely!We can customize trailers or trucks according to your requirements.
