Model NO.
SWT-BT64-L
Axle Number
1
ABS
With ABS
Tire Size
11.00-20
Condition
New
Model No
Swt-Bt64-L
Size
1800X1200mm(Other Size Can Be Chosen)
Axle
50X50mmx4mm Square Tube Axle
Chassis
50X50 Rhs (Not Angle)
Spring
5 Leafs Spring (Not Cheap 3 or 4 Leafs)
Wheel
165/70r13 Wheel with 13inch White Paint Rim
Drawbar
70X50 Rhs
Floor & Sides
Checker Plate
Max Payload
750kgs
Surface Treatment
Hot Dipped Galvanized
Transport Package
Flat Packing
Trademark
SWT
Origin
Jiangsu, China (Mainland)
Production Capacity
600 Set/Sets Per Month
Type:
Full Trailer
Loading Weight:
2T
Certification:
DOT
Grade:
Light Duty
Tire Number:
2
Color:
White
BETTER PRICES, BETTER QUALITY
Light Duty Fully Welded Box Trailer 6X4
PAYMENT TERM & DELIVERY TIME
30% deposit .70% balance will be paid after we send copy of B/L
28 days after we get deposit
WARRANTY
1 year for trailer parts.
12 years for trailer box and drawbar and cage.
12 years for trailer hot dipped galvanized.
Light Duty Fully Welded Box Trailer 6X4
| Different Sizes For Light Duty Fully Welded Box Trailer | |||||||
| SIZE | MODEL NO | OVERALL SIZE | INNER BOX SIZE | SPRING | WHEEL | SURFACE TREATMENT | GVW |
| 6x4Ft | SWT-BT64-L | 3110x1720x800mm | 1800x1200mm | 5leafs | 165/70R13 | Hot Dipped Gal | 750KGS |
| 7x4Ft | SWT-BT74-L | 3410x1720x800mm | 2100x1200mm | 5leafs | 165/70R13 | Hot Dipped Gal | 750KGS |
| 7x5Ft | SWT-BT75-L | 3410x2025x800mm | 2100x1525mm | 5leafs | 165/70R13 | Hot Dipped Gal | 750KGS |
| 8x5Ft | SWT-BT85-L | 4740x2025x800mm | 2440x1525mm | 5leafs | 165/70R13 | Hot Dipped Gal | 750KGS |
| Description For Light Duty 6x4 Box Trailer | |
| Drawbar | 70x50 RHS. 1200mm long with 8mm safety chain (Chain with AS4177 stamp) |
| Chassis | 50X50 RHS (Not angle) |
| Floor & Sides | Checker plate (Not cheap Ribbed zinc plate) |
| Axle | 50x50x4mm Square tube axle |
| Spring | 5leafs spring (not 3leafs or 4leafs cheap and light spring) |
| Wheel | 165/70R13 wheel with 13inch white paint rim |
| Jockey wheel | 6inch top wind heavy duty jockey wheel. with E-mark and DOT certificate |
| Coupling | 50mm AU standard coupling, 1 7/8 NZ standard coupling, EU standard coupling |
| Lights | Led Lights with 7pin plug and 7 core wiring. light with E-mark and DOT certificate |
| Surface Treatment | Hot dipped galvanized |
PAYMENT TERM & DELIVERY TIME
30% deposit .70% balance will be paid after we send copy of B/L
28 days after we get deposit
WARRANTY
1 year for trailer parts.
12 years for trailer box and drawbar and cage.
12 years for trailer hot dipped galvanized.
