Model NO.
CSC94077
Independent Suspension Type
Trailing Arm Type
Shape
Flatbed
Axle Number
3 Axles
Tire Number
12 Pieces with One Spare
Self-dumping
Not Self-dumping
ABS Anti-lock Braking System
ABS Anti-lock Braking System
Material
Steel
Condition
New
Axle Brand
BPW, Fuwa, L1, Hj etc
Loading Capacity
40t, 50t, 60t, 80t, 100t etc
Product Name
3 Axle Lowbed, Low Bed, Lowboy, Low Loader Trailer
Number of Axle
2 Axle, 3 Axle, 4 Axle
Suspension
Mechanical Suspension, or Air Bag
Landing Gear
Jost 28ton
King Pin
Jost Brand 50, 90
Tire
11r22.5 Tubeless Tire
Shipping Way
by Bulk Ship. or by Container Loading
Application
Heavy Machine Equipments
Transport Package
Naked or Waxed Before Shipment
Specification
60 tons, 100 tons
Trademark
CSC
Origin
Suizhou Hubei
HS Code
8701200000
Production Capacity
10000 Units Per Year
Type:
Semi-Trailer
Load Capacity:
60t, 80t, 100t
Certification:
ISO9001, CCC, ISO/TS16949
Wheel Base:
9000-10000mm
Tread:
1820mm
Grade:
Heavy Duty
Above lowbed semi trailer can maximum load 80tons cargo with mechanical ramps, hydraulic ramp is also available for choose.
The 80tons lowbed truck trailer length 13000mm, width 3000mm, height 1700mm.
Eqipped with Heavy duty and extra durability designed I beam; Opting for high tensile steel Q345B, welded by automatic Submerged-Arc processes. Top Flange 22mm, Middle Flange 12mm, Bottom Flange 25mm.
Eqipped with Heavy duty and extra durability designed I beam; Opting for high tensile steel Q345B, welded by automatic Submerged-Arc processes. Top Flange 22mm, Middle Flange 12mm, Bottom Flange 25mm.
The axle is 13tons, FUWA brand (BPW axle available)
Mechanical suspension (air suspension available)
Floor 5mm checker plate
Leaf spring 10 pieces, 16mm thick
King pin JOST brand 3"
Landing gear JOST brand
Tire 315/80R22.5 tubeless tire, 20 pieces in total
Braking system T30/30 spring brake chamber
ABS equipped
Mechanical suspension (air suspension available)
Floor 5mm checker plate
Leaf spring 10 pieces, 16mm thick
King pin JOST brand 3"
Landing gear JOST brand
Tire 315/80R22.5 tubeless tire, 20 pieces in total
Braking system T30/30 spring brake chamber
ABS equipped
Our factory can also produce 20FT or 40FT flatbed semi trailer, drop side semi trailer, storehouse semi trailer, rear dump semi trailer, side dump truck trailer etc.
1. Hubei Chusheng Vehicle Co., Ltd. is a famous and one of the biggest manufacturer with very professional experience in special automobile field for more than 15 years in China. We have more than 3000 workers, 400 technicians, and factory scale is more than 690,000m2.
2. Our most advantage and leading products including LPG tanker series, Water Tank, Fuel tank, Refrigerated Truck, Garbage Truck, Towing/Wrecker truck, Dump Truck, Sewage Suction Truck, Concrete Mixer Truck, Bulk Cement Truck, Van Truck, Sweeper Truck, Truck with Crane, Fire fighting Truck, High-altitude Operation Truck, Chemical Liquid Truck, Milk Transport Truck, LED Display Truck, Various Semi-trailer, Spare parts etc.
3. We have successfully exported to more than 60 countries, such as Ghana, Togo, Sudan, Kuwait, Peru, Nigeria, Benin, Angola, Tajikstan, Azerbaijan, Namibia, Burma, Korea,Philippines, Vietnam, Saudi Arabia, Mexico, Chile, Bolivia, Tanzania, Zambia, Zimbabwe, Yemen etc.
4. We have strict quality control of raw material, professional management team and technical workers, advanced equipment, strict inspection before delivery, excellent packing and shipping team.
