Model NO.
QT-semitrailer
Tread
1310
Grade
Light Duty
Independent Suspension Type
Trailing Arm Type
Shape
Skeleton
Axle Number
2axle
Tire Number
4
Self-dumping
Not Self-dumping
ABS Anti-lock Braking System
ABS Anti-lock Braking System
Material
Steel
Condition
New
Transport Package
Roro, Bulk Cargo, Container
Specification
12500x2500x1580mm
Trademark
Qingte or OEM
Origin
Qingdao
HS Code
8716399000
Production Capacity
50000 Units/Year
After-sales Service:
3 Years
Warranty:
5 Years
Type:
Semi-Trailer
Load Capacity:
50T
Certification:
ECE, CE, ISO9001, CCC, ISO/TS16949
Wheel Base:
1820mm
Made in China Semi Trailer 2 Axles Container Chassis Truck Skeleton Semi Trailer
Providing supporting and processing on Semi Trailer
20FT Skeleton Semi Trailer/ 20FT Container Semi Trailer
40FT Skeleton Semi Trailer/ 40FT Container Semi Trailer
45FT Skeleton Semi Trailer/ 45FT Container Semi Trailer
2X20FT Skeleton Semi Trailer/ 2X20FT Container Semi Trailer
CKD/SKD situation Available
OEM/ODM acceptable
20FT Skeleton Semi Trailer/ 20FT Container Semi Trailer
40FT Skeleton Semi Trailer/ 40FT Container Semi Trailer
45FT Skeleton Semi Trailer/ 45FT Container Semi Trailer
2X20FT Skeleton Semi Trailer/ 2X20FT Container Semi Trailer
CKD/SKD situation Available
OEM/ODM acceptable
Container transport vehicle is a type of putting varieties, different shapes, different size of goods into the standard container in order to facilitate the combined transport of water, land, and air transportation mode. It can realize loading and unloading directly, transportation mechanization, standardization. Skeleton design and flatebed design are the two popular design focus on the container transport.The skeleton semitrailer is called container semitrailer/skeleton semitrailer/container chassis trailer. According to the size of container, different model skeleton semi trailer can be supplied like 20FT, 40FT, 2X20FT, 45FT, 48FT skeleton container.
| Semi trailer Dimension | 12500mmX2500mmX1580mm |
| Tare weight | 6T |
| payload | 30-40T |
Chassis
| Main beam | Heavy duty and extra durability designed I beam; Opting for high tensile steel Q345B, welded by automatic Submerged-Arc processes. |
| Frame Beam | Top Flange 14mm,width 140mm; Middle Flange 8mm; Bottom Flange 16mm,width 140mm, main beam height 500mm |
| Axle | 2 axles, 16Ton Fuwa/BPW/YUEK brand 16ton brake pads |
| Landing Gear | 28T lifting capacity with two speed |
| King Pin | JOST 2.00 or 3.5 inch bolt-in king pin |
| Suspension | Mechanical/Bogie/Air Suspension |
| Leaf Spring | 90mm(W)*13mm(T)*13 Layer |
| Pneumatic Braking System | Dual line pneumatic brake system,T30 air chamber ,40L air tanks, WABCO Emergency relay valve |
| Rim | 9.0-20*12 pcs |
| Tire | 12R22.5*12 pcs |
| Accessories | One standard tool box |
| Spare tire rack | One |
| Electrical system | 24 volt electrical system.7 pin electrical connector. Parking stop, reverse, number plate and indicator lights. rear lights conform to European standard, rear front and side reflectors |
| Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
Qingte Group is a diversified enterprise specialize in Special Vehicle, drive axle, trailer axle , and auto parts like gears and casting with the strength of good quality and pretty competitive price. And real estate.
Sincerely hope to establish communication with you for any possible cooperation in the market
Customized special trailers manufacture and Qingte own design trailer export.
Our main trailers including Cargo transport, flatbed, side wall trailer and skeletal semitrailers, Low bed trailer,Tank semitrailers, Modular Trailers (Hydraulic multi axle trailer), SPMT (Self-propelled Modular Transporters),trailer for wind power industry, etc
With rich processing experience and practical expertise, Solid, Durable, and Powerful quality products can be supplied.
We know how to make better bodies for semi-trailers, dumpers, and trucks
Sincerely hope to establish communication with you for any possible cooperation in the market
Customized special trailers manufacture and Qingte own design trailer export.
Our main trailers including Cargo transport, flatbed, side wall trailer and skeletal semitrailers, Low bed trailer,Tank semitrailers, Modular Trailers (Hydraulic multi axle trailer), SPMT (Self-propelled Modular Transporters),trailer for wind power industry, etc
With rich processing experience and practical expertise, Solid, Durable, and Powerful quality products can be supplied.
We know how to make better bodies for semi-trailers, dumpers, and trucks
