High Quality 3 Axles 40 Feet Container Transport Trailer Flat Truck Semi Trailer For Sale
Flatbed semi-trailer with container structure for the loading part. Mainly used for ships, ports, routes, highways, transit stations, bridges, tunnels, multimodal transport matching logistics systems.1. Specially used for the transport of various containers. It can be used repeatedly for a long time and has sufficient strength.
2,The use of container transit goods, can be directly in the consignor's warehouse loading, transported to the consignee's warehouse unloading, midway to replace the car, ship, without the goods from the box out of the change.
3, can be quickly loaded and unloaded, and can be directly from a means of transport convenient change to another means of transport.
4,It is easy to fill and unload the goods, to meet the individual needs of customers. According to customer needs workwear guarantee, stable quality and reliable performance.
Specification of flat semi trailer
| Product parameters (main configuration) | ||||
| Specification | Overall dimensions | 12500*2500*1560mm | Internal dimensions | |
| Height of traction pin | 1300mm | Front/rear suspension | ||
| wheelbase | 1310mm | Track width | 1840mm | |
| Frame body configuration | Item | texture of material | Specifications | |
| Girder | Q345 | Height 500mm, width 140mm, upper wing plate 14mm, lower wing plate 16mm, vertical plate 8mm; | ||
| beam | Q345 channel steel | 100mm channel steel | ||
| Side beam | Q345 channel steel | 16 # channel steel | ||
| floor | Q235 | 3mm | ||
| parts | suspension | 3-axle mechanical suspension | Leaf spring | 90 * 13 * 10-6 frames |
| Axle specification/brand | 13T/1840 Fuhua | Number of axles | 3 | |
| Tyre specification/brand | 12R22.5/CHENGSHAN | Number of tires | 12 | |
| Steel ring specification/brand | 9.0-22.5 | Number of steel rims | 12 | |
| Outrigger specification/brand | 28T/Yahua | Traction pin specification | 50 # or 90 # interchangeable type | |
| Brake system | Brake valve brand | WABCO | Specification/quantity of brake chamber | T30/30-6 |
| Brake system | Emergency braking system, air braking, double air pipeline, 6 T30/30 brake chambers, 2 40L air reservoirs | |||
| Electrical circuit system | Circuit socket | 7-hole socket | Voltage | 24 |
| lamps and lanterns | LED light | Two rear tail lights (including two steering lights, two brake lights and two constant lights), eight side lights and two rear triangular reflectors; | ||
| enclosure | hold-all | 1 tool box | tool | Shaft end wrench, rocker |
| Spare wheel holder | 1 | |||
| colour | According to customer requirements | |||
| remarks | Locking hands: 8 | |||
The details of flat semi trailer
Packing and shipping of truck semi trailers
Our Factory
1. Advanced equipment and rich experience worker are applied during the whole producing process to ensure the quality of semi trailer.
2. For each semi trailer, we must do the testing and inspect the quality,and we have many QC&QA people on the production process and the testing process and warehouse to guarantee the quality of the every details.
3. Inspection according to customer demand for every semi trailer which given by an independent third party certification company.
4. Warranty for semi trailer usually is 12months,Technical support for life.
Our company Certifications
Related Products of truck semi trailer
Related Products of tanker semi trailer
Customer visiting
