Model NO.
SGZ
Tread
1820mm
Grade
Heavy Duty
Independent Suspension Type
Cross Arm Type
Shape
Van-type
Axle Number
3
Tire Number
12
Self-dumping
Not Self-dumping
ABS Anti-lock Braking System
No ABS Anti-lock Braking System
Material
Steel
Condition
New
Color
Grey or as Customers′ Option
Logo
Can Be Designed as Customers′ Option
Axle Brand
BPW/Fuwa/Hj
Loading Capacity
50000kg
Suspension
Mechanical Suspension
Transport Package
Nude Pack
Specification
ISO
Trademark
Sinotruk Huawin
Origin
China
HS Code
8701
Production Capacity
1000 Units/Month
After-sales Service:
24 Hours After-Sale Service
Warranty:
6 Months
Type:
Semi-Trailer
Load Capacity:
50 Ton
Certification:
CE, ISO9001, CCC
Wheel Base:
7000-8000mm
Specifications
| I Beam & chassis | Heavy duty and extra durability designed I beam; welded by automatic Submerged-Arc processes. |
| Axle | 3 axles. BPW brand, 13 ton loading capacity. |
| Suspension | Spring suspension |
| King Pin | JOST brand 2" Bolt-in King Pin |
| Landing Gear | JOST brand Two-speed, manual operating, heavy duty landing gear |
| Wheel Rim | 13.0-22.5 wheel rim, aluminum alloy material |
| Tire | 425/80R22.5 super single tubeless tire, Double Coin brand. One spare tire. |
| Box | Inner Size(length*width*height): 13750*2410*2650mm, high density polyurethane for insulation. |
| Accessories | One standard tool box |
| Cooling system | America brand Termo King SLXe-400 independent cooling system with backup electric power system. |
| Working temperature: - 20ºC ~ +27 ºC | |
| Independent generator: TK486V, 23.5 KW. | |
| Compressor: model X430 C5, displacement: 492cm³ | |
| Emergency power supply: 380V/3Ph/50Hz, 9.3kw | |
| Cryogen: 7.5kg. | |
| Overall Size(mm) | 14600*2600*4150 |
