Model NO.
LTH9400TJZ
Type
Semi Trailer
Load Capacity
40t
Certification
ISO9001, CCC, ISO/TS16949
Wheel Base
4200+1300mm
Tread
1840mm
Grade
3700kg
Independent Suspension Type
Merchanical Tandem Suspension
Shape
Flatbed
Tire Number
8
Self-dumping
Not Self-dumping
ABS Anti-lock Braking System
ABS Anti-lock Braking System
Material
Steel
Condition
New
Total Weight
35000kgs
Rear Overhang
1000mm
Tire
1100r20, 11r22.5, 12r22.5
Axle
Fuwa Brand, 13t Capacity
Suspension
German / American Type
Kingpin
90#(3.5 ′′)
Cross Beam
Q345b, 16# Channel Steel
Landing Gear
Jost or Other Chinese Brand, 28ton
ABS
4s/2m
Brake System
30/30 Type on Each Axle,Wabco / Haldex Brake Valve
Trademark
CTSM
Transport Package
Nude
Specification
7000 x 2400 x 1550 mm
Origin
Shandong, China
HS Code
87164000
Our products have been exported to Southeast Asia, Middle East, Russia, Africa and South America and won excellent reputation.
With complete and advanced manufacturing facilities, 100% after sales warranty, 24 hours technical support, the quality and after-sale service can be well ensured.
** 12 years experience
** Quality materials such as Mn16, Q235 and Q345
** Ensure the exquisite workmanship by using automatic submerged arc welding machine
** Using the shot blasting machine to treat the surface
** OEM for China main heavy truck enterprises such as FAW, SAG and Sinotruck.
2 axles Straight Beam 20ft container transport skeleton semi-trailer
| Main Specification | |||||||
| Type | 2 Axles 20ft Container Transport Semi-trailer | ||||||
| Overall dimension(mm) | 7000 x 2480 x Height (depend on the tractor fifth-wheel clearance) | ||||||
| Loading Weight(Kg) | 40000 | ||||||
| Main beam | Straight Beam. Straight Beam. 500 mm deep submerged arc welded I-beam, upper plate is 12mm, down plate is 14mm, middle plate IS 6mm. | ||||||
| Side Beam | 14mm cold forming sectional steel | ||||||
| Cross Beam | W-shape high strengthed steel | ||||||
| Color | depand on the customer's requirement | ||||||
| Chassis | |||||||
| King pin | 90# (3.5") | ||||||
| Landing gear | Standard 28ton | ||||||
| Axle | 2 Axles, FW13TBII | ||||||
| Suspension | 60pin standard suspension | ||||||
| Leaf Spring | 10/10/10 | ||||||
| Tire | 12R22.5, 9 sets(include one spare tire) | ||||||
| Twist lock | 4sets | ||||||
| Accessories | |||||||
| Brake | 2 Double-chamber and 2 Single-chamber, with ABS | ||||||
| Tool Box | 1 unit | ||||||
| Spare Wheel Carrier | 1 unit | ||||||
| Side Marker Lamp | LED type | ||||||
| Voltage | 12V | ||||||
| Receptacle | 7ways (7 wire harness) | ||||||
| Transport treatment | |||||||
| Painting | Sandblasting treatment before painting, Zinc-rich primer and urethane based topcoat. | ||||||
| Anticorrosion treatment | Wax spray treatment to prevent corrosion during the ocean transportation. | ||||||
***OEM is acceptable
FAQ:
1.What's the MOQ?
1 unit
2.Delivery time?
Usually the delivery time is 10 days, at peak season, about 20 days.
3.Whether the spare parts can be shipped with the semi trailer?
Yes, we can ship the spare parts such as axles, landing legs, suspensions, tires and other spare parts with the trailer.
4.Are you a manufacturer?
Yes, we have been in special vehicle manufacturing and marketing for 12 years.
5.. What information should I provide for the quotation?
You should provide the information such as road condition, cargo type, loading capacity, dimensions of trailer, quantity.....and so on.The price and delivery time is as per the order quantity.
6. Terms of payment:
T/T or L/C at sight.
7. What's your warranty?
All the trailers are produced in strict with ISO standard, we will be responsible for the manufacturer failure.
8.Should we make a factory tour and inspect the trailer before loading?
Yes, we welcome you to the factory tour and inspect the trailer by yourself or the third authorized party such as SGS, TUV,B.V. etc..
