Our girder trailer is special for transporting girder, which has been used in China market for several years. It is special for very narrow road.
175ton girder trailer specification:
1. Rated (max.) loading capacity(kg): 175,000
2. Kerb weight(kg): 33,500
3. Max. total weight: 208,500
4. Axle rated (max.) loading capacity(kg):(7,500X6=)45,000
5. Gooseneck(the fifth wheel) loading capacity(kg): 17,500
6. Max. (Rated) speed(km/h): 35
7. Rated (loading) speed(km/h)/loading(kg) ----
8. Dimension(length X width X height)(mm): 25,000X3,000X1,830
9. Platform dimension(length X width)(mm) ---
10. Front trailer(flat bed trailer)
a. Kerb weight(kg): 12,000
b. Rated(max.) loading capacity(kg) :87,000
c. Max. total weight(Kg):99,000
d. Wheel base(mm) ---
e. Track(mm) ---
f. Front overhang(mm) ---
g. Rear turning radius(mm): 2,300
h. Height of the fifth wheel(mm): 1,380
i. Rear overhang(mm) ---
j. Departure angle (º) ---
k. Tyre: 8.25R20
l. Tyre quantity: 24pc
m. Suspension type: Tandem floating rigid suspension
n. Axle quantity: 6pc(fixed)
o. Control steering max. angle(º) ---
p. King pin: 90#(88.9mm)(or as per user's requirement)
q. Frame type: flat grid
r. Basic material: Q550D,Q345
s. Main beam material: Q550D
t. Electric signal system ISO voltage(V): 24
u. Braking system ISO: Dual pipe control, shoe type brake (on all wheels)
11. Rear trailer(dolly)
v. Kerb weight(kg): 12,000
w. Rated(max.) lading capacity(kg) :88,000
x. Max. total weight(Kg): 100,000
y. Wheel base(mm) ---
z. Track(mm) ---
aa. Front overhang(mm) ---
bb. Rear turning radius(mm) ---
cc. Height of the fifth wheel(mm) ---
dd. Rear overhang(mm) ---
ee. Departure angel(º) ---
ff. Tyre: 11.00R20
gg. Tyre quantity: 20pc
hh. Suspension type: Tandem floating rigid suspension
ii. Axle quantity: 2pc(fixed) and 3pc (steering)
jj. Control steering max. angle(º) 35 º
kk. Steering control type: automatic and manual
ll. Power pack: 12Kw, single cylinder engine (Chang chai)
mm. Frame type: flat grid
nn. Basic material: Q550D, Q345
oo. Main beam: Q550D
pp. Electric signal system ISO voltage(V): 24
qq. Braking system ISO: Dual pipe control, shoe type brake (on all wheels)
