Wittur Landing Door Installation on The Existing Door Frame Possible, Elevator Parts, Elevator Door

Supplier Shanghai Sunny Elevator Co., Ltd.
Price $435.00 / Piece
Availability In Stock
Mini Order:
+-
Subtotal: $435

Purchase details

Payments:

Tax:

Tax Included

Returns&Refunds:

Eligible for refunds within 30 days of receiving products. returns and refunds

Model NO.
FINELINE Landing Door
Speed
2.0m/S
Drive Mode
AC
Control Type
Microcomputer Frequency Control
Lift Mechanism
Telescoping Lift
Use of Occasions
Public Traffic
Guide Rail
T Guide
Model
Wittur
Used
Elevator Parts
Clear Height
1900 - 2100mm
Co
600~900
C2/Sill Package
85mm
Transport Package
Wooden Box
Trademark
Wittur
Origin
China
Production Capacity
10000PCS/Month

WITTUR FINELINE Landing Door Installation On The Existing Door Frame Possible

Fineline® incomparable compact sill design contributes to space saving: it can fit even in the smallest shafts.

This door sets new standards with its compact size and sill dimensions.

Advantages:

  • Extremely compact door designed to insert an automatic door with a minimal depth
  • The door is particularly evident when modernizing an existing elevator with swing doors
  • No modifications of the existing walls needed (installation on the existing door frame possible)

Technical sheet

Elevator Rated SpeedUp to 2 m/s
Clear Opening (mm)600 - 900
Clear Height (mm)1900 - 2100
C2/Sill Package (mm)85
T2/Sill Package (mm)115
T3/Sill Package (mm)-
C4/Sill Package (mm)Symmetrical 115 - Asymmetrical 115
C6/Sill Package (mm)-
T1/Sill Package (mm)-
Full Glass-
Framed Glass-
EN 81-20/50Standard
EN 81-71-
EN 81-72-
EN 81-58 EOptional
EN 81-58 EI-
BS 476 E-
GOST 53780/53871-
Aluminium SillStandard
Reinforced Sill-
Hidden Sill-
Door ClosingCounterweight


Wittur Landing Door Installation on The Existing Door Frame Possible
Wittur Landing Door Installation on The Existing Door Frame Possible
Wittur Landing Door Installation on The Existing Door Frame Possible
Wittur Landing Door Installation on The Existing Door Frame Possible
Wittur Landing Door Installation on The Existing Door Frame Possible
About us
Wittur Landing Door Installation on The Existing Door Frame Possible
Why choose us?
Shanghai Sunny Elevator Co., Ltd, founded in 1992, is a 30-year professional manufacturer specializing in designing and producting Opto-Electro-Mechanical products.
Sunny Elevator has started import and export since 2012.
We have experience in exporting all kinds of elevator parts and complete elevator to 80 countries all over the world.
