Model NO.
3A
Weight
16.5 Kg
Full Throttle Operating Range
4500-5500 R/M
Gear Position
Forward-Neutral
Transport Package
Carton
Specification
CE, SGS, ISO9001
Trademark
EARROW
Origin
Zhejiang China
HS Code
8407210000
Production Capacity
15000 Sets Per Year
Cylinders:
1
Fuel Type:
Gasoline
Engine:
2 Stroke
Engine Position:
Outboard
Condition:
New
Displacement:
70.0cc
Advantages:
1. Our engineer comes from BRP factory with rich design, test and production experience.
2. Most plastic and die casting parts are made by ourself with expensive raw material and strict quality control.
3. We now dedicate ourself to small horse power in order to make this product range competive against Top three brand.
| Model | 3A |
| Dimension | Overall length: 628mm (24.7 in) Overall width: 289 mm (11.4 in) Overall height S: 997 mm (39.3 in) Overall height L: 1124 mm (44.3 in) |
| Weight | S: 16.5 Kg (36lbs) L: 17 Kg (37.5lbs) |
| Full Throttle Operating Range | 4500-5500 r/m |
| Maximum Output | 2.2kw/3hp |
| Idling Speed | 1200±50r/m |
| Type | Two Stroke |
| Displacement | 70.0cc |
| Bore×Stroke | 46.0×42.0mm(1.81×1.65 in) |
| Ignition System | CDI |
| Spark Plug | NGK BR7HS-10 |
| Spark Plug Gap | 0.9-1.0mm |
| Control System | Tiller Handle |
| Starting System | Manual |
| Starting Carburation System | Choke Valve |
| Gear Position | Forward-Neutral |
| Gear Ratio | 2.08 (27:13) |
| Trim and Tilt System | Manual Tilt |
| Recommended Fuel | Unleaded Gasoline |
| Recommended Engine Oil | 2-stoke outboard motor oil |
| Fuel Oil Ratio | 50:1 |
| Gear Oil | 0.075 L |
| Fuel Tank Capacity | 1.4 L |
