Stud Link Chains for Marine Anchor
| Product name | Stud Link Chains for Marine Anchor |
| Place of origin | Shandong China |
| Brand | LS |
| Material | CM490/690 |
| Size | 14mm-130mm |
Ports | Port of Qingdao |
| Sample | The sample is free,the freight should on your account before your first order. |
| Surface | Bitumen |
| Payment term | T/T, Western Union or L/C at sight |
| Delivery time | Usually within 15-30 days according to your required size&quantity. |
| Using range | Marinr chain;Fishing&boat;main chain;cement lifting round chain |
| Service | Your inquiry will be replied within 12 hours. |
Sample Delivery:
1)The sample for free.
2)Please show us your Express Account No. and control No. at the first order.
Lisheng Trading, with more than 10 years of experience in manufacturing and exporting, has created a good reputation in lines of Link Chain, Rigging Hardware, Rope, Plastics and the related. Aiming to become industry elite and achieve sustained growth in global market, our main products cover standards of DIN, EN, JIS, UN, etc., of which the quality are guaranteed by Quality System of ISO9001.
| Stud and studless link anchor chain Size(6×3.6D) Proof Load Weight |
| Diameter | Size | U1 stud link anchor chain | U2 stud link anchor chain | U3 stud link anchor chain | Weight |
| D(φ) |
| | Outside length | Outside width | Proof load | Breaking load | Proof load | Breaking load | Proof load | Breaking load | 27.5M |
| | L | B |
| | | |
| Inch | mm | mm | mm | KN | KN | KN | KN | KN | KN | KG |
| 1/2 | 12.5 | 75 | 45 | 46 | 66 | 66 | 92 | 92 | 132 | 98 |
| 9/16 | 14 | 84 | 50.4 | 58 | 82 | 82 | 116 | 116 | 165 | 119 |
| 5/8 | 16 | 96 | 57.6 | 76 | 107 | 107 | 150 | 150 | 216 | 156 |
| 11/16 | 17.5 | 105 | 63 | 89 | 127 | 127 | 179 | 179 | 256 | 186 |
| 3/4 | 19 | 114 | 68.4 | 105 | 150 | 150 | 211 | 211 | 301 | 230 |
| 13/16 | 20.5 | 123 | 73.8 | 123 | 175 | 175 | 244 | 244 | 349 | 260 |
| 7/8 | 22 | 132 | 79.2 | 140 | 200 | 200 | 280 | 280 | 401 | 300 |
| 15/16 | 24 | 144 | 86.4 | 167 | 237 | 237 | 332 | 332 | 476 | 370 |
| 1-1/16 | 26 | 156 | 93.6 | 194 | 278 | 278 | 389 | 389 | 556 | 431 |
| 1-1/8 | 28 | 168 | 100.8 | 225 | 321 | 321 | 449 | 449 | 642 | 496 |
| 1-3/16 | 30 | 180 | 108 | 257 | 368 | 368 | 514 | 514 | 735 | 564 |
| 1-1/4 | 32 | 192 | 115.2 | 291 | 417 | 417 | 583 | 583 | 833 | 635 |
| 1-5/16 | 34 | 204 | 122.4 | 328 | 468 | 468 | 655 | 655 | 937 | 712 |
| 1-7/16 | 36 | 216 | 129.6 | 366 | 523 | 523 | 732 | 732 | 1050 | 800 |
| 1-1/2 | 38 | 228 | 136.8 | 406 | 581 | 581 | 812 | 812 | 1160 | 887 |
| 1-9/16 | 40 | 240 | 144 | 448 | 640 | 640 | 896 | 896 | 1280 | 1032 |
| 1-5/8 | 42 | 252 | 151.2 | 492 | 703 | 703 | 981 | 981 | 1400 | 1084 |
| 1-3/4 | 44 | 264 | 158.4 | 538 | 769 | 769 | 1080 | 1080 | 1540 | 1197 |
| 1-13/16 | 46 | 276 | 165.6 | 585 | 837 | 837 | 1170 | 1170 | 1680 | 1310 |
| 1-7/8 | 48 | 288 | 172.8 | 635 | 908 | 908 | 1270 | 1270 | 1810 | 1438 |
| 2 | 50 | 300 | 180 | 686 | 981 | 981 | 1370 | 1370 | 1960 | 1546 |
| 2-1/16 | 52 | 312 | 187.2 | 739 | 1060 | 1060 | 1480 | 1480 | 2110 | 1661 |
| 2-1/8 | 54 | 324 | 194.4 | 794 | 1140 | 1140 | 1590 | 1590 | 2270 | 1791 |
| 2-3/16 | 56 | 336 | 201.6 | 851 | 1220 | 1220 | 1710 | 1710 | 2430 | 1926 |
| 2-5/16 | 58 | 348 | 208.8 | 909 | 1290 | 1290 | 1810 | 1810 | 2600 | 2086 |
| 2-3/8 | 60 | 360 | 216 | 969 | 1380 | 1380 | 1940 | 1940 | 2770 | 2249 |
| 2-7/16 | 62 | 372 | 223.2 | 1030 | 1470 | 1470 | 2060 | 2060 | 2940 | 2361 |
| 2-1/2 | 64 | 384 | 230.4 | 1100 | 1560 | 1560 | 2190 | 2190 | 3130 | 2516 |
| 2-9/16 | 66 | 396 | 237.6 | 1160 | 1660 | 1660 | 2310 | 2310 | 3300 | 2676 |
| 2-11/16 | 68 | 408 | 244.8 | 1230 | 1750 | 1750 | 2450 | 2450 | 3500 | 2885 |
| 2-3/4 | 70 | 420 | 252 | 1290 | 1840 | 1840 | 2580 | 2580 | 3690 | |
It is Lisheng who pay much attention on business ethics. The team believes in maintaining win-win situation relationships with all clients. Taking quality products and clients' satisfaction as the core value, the company respects every customer and spares no effort to cater to diverse needs of business partners. The dedication and honesty we show toward our works transforms us into a reliable name among clients. We aspire to bring our products to broader market and share benefits with more customers upon better service.
