Floating Solar panels Mounting Systemis applied to solar power plant installation on the water. Adopting HDPE material, Anti-Aging, Anti-UV etc. Moreover, it can bear the pulling force that is much higher than other products. Adopting new module design in floater and main floater, it can realize the array of double row in the same facing or in symmetrical facing, which can increase the efficiency of solar power generation and installation capacity, be easily installed, and save the cost. and its lifetime has more than 15 years.
1. Modular design, simple and convenient splice installation;
2. Increase the volume of floater to add the buoyant force of floater;
3. The floater is made of high density polyethylene, which ensures its long service time;
4. Various array design, easier to combine;
5. Realize symmetrical facing array, increase the installation capacity, maximize
6. the efficiency of power generation;
7. Compatible with various solar module, save the cost;
8. Strong weather ability, easy to operation and maintenance.
| Product name | Floating PV Mounting System |
| Material | HDPE |
| Color | Gray or Customized |
| Installation Site | Lake, Reservoir |
| Tilt Angle | 10° / 15° |
| Wind Load | 51m/s |
| Snow Load | 1KN/m2 |
| Water Surface Clearance | 330-350mm |
| Module Type | Frame or Double Glass |
| Panel Orientation | Landscape, Double Row In The Same/ Symmetrical Facing |
| Bearing Weight | Main floater70KG/m2, Channel 155KG/m2 |
