Model NO.
sleeper
Length
2500mm
Part
Railway Rail
Type2
Turnout Sleepers
Width 2
220mm
Thickness 2
160mm
Length 2
2500mm
Delivery Time
5-10 Days After Your Payment
Transport Package
Export Standard Carton Box/Wooden Box Package
Specification
Bs, ASTM and DIN, SGS. ISO. CE
Trademark
China Coal
Origin
Jining City, Shandong Province
HS Code
73029010
Production Capacity
1000PCS/Month
Customized:
Customized
Certification:
CE,SGS, TUV, BV
Type:
Sleeper
Type1:
Normal Sleepers
Width:
220mm
Thickness:
160mm
Introduction of Railroad Sleeper 1.2M Railway Concrete True Sleeper
Concrete sleeper is also called concrete pillow, pillow, also known as concrete. Made of concrete, reinforcement, combination and become, appearance is hard, long service life. Concrete sleepers in accordance with the installation can be divided into U-shaped ring and pressure plate bolts. U-shaped concrete sleepers ring easy to install, simply put the rail between two U-rings, rubber pad underneath it, and then using a sledgehammer spending a U-shaped loop to suppress rail. Concrete sleepers bolt plate is to use T-bolt holes from piercing reserved sleeper following fixed platen press and hold the rail above, a sleeper requires four sets of bolts, 4 plate, two rubber pads, this sleeper easy maintenance , can be reused.zmwm02Parameter of Railroad Sleeper 1.2M Railway Concrete True Sleeper
| 1.Normal sleepers | Width 220mm; thickness 160mm; length 2500mm; |
| 2.Turnout sleepers (Normal) | Width 220mm; thickness 160mm; length 2600 ~ 4850mm, with 150mm carry a total of 16 lengths; |
| 3.Turnout sleepers (Standard) | Width 240mm; thickness 160mm; length 2600 ~ 4800mm, with 200mm carry a total of 12 lengths; |
| 4.Bridge sleepers | Width 220mm; thickness 240,260,280,300 mm; length 3000mm. |
Photos of Railroad Sleeper 1.2M Railway Concrete True Sleeper
