Model NO.
JG-3boom
Arm Length
1850mm
Transport Package
Nude Packing
Specification
5400*2500*3200mm
Trademark
JingGong
Origin
China
HS Code
8429521100
Production Capacity
3000units/ Year
After-sales Service:
Yes
Warranty:
1 Year
Customized:
Customized
Certification:
ISO9001
Type:
Customization
Boom Length:
3680mm
Our company abides by the business philosophy of "quality first, customer first" to ensure product quality. We have rigorous production procedures, and each production process is carried out under strict quality inspection.Only after passing the inspection can they move on to the next procedure. At the same time, we insist on creating a neat, clean and safe working environment.
Company
We are a leading manufacturer and exporter of wheel excavators, crawler excavators, sugarcane harvesters, sugarcane grab loaders, multi-function excavators. We have nearly 20 years of professional experience, and our products have been exported to many countries.
Exhibition Show
Certificates
| SPECIFICATIONS | ||||||||||
| RANGE OF OPERATION | Boom length | 3680mm | ||||||||
| Arm length | 1850mm | |||||||||
| Max Extended Distance of Arm | 800mm | |||||||||
| Max Lifting Height of Cab | 1800mm | |||||||||
| Width of Leveler | 2500mm | |||||||||
| Maximum leveling height | 3800mm | |||||||||
| Back-end radius of gyration | 1800mm | |||||||||
| DIMENSION | (Length*width*height) travel position | 5400*2500*3200mm | ||||||||
| Wheel base | 2590mm | |||||||||
| Track(Front/rear) | 1850mm/1750mm | |||||||||
| Ground clearance of counterweight | 1060mm | |||||||||
| Min ground clearance | 200mm | |||||||||
| TECHNICAL PARAMETERS | Angle of rotation | 360° | ||||||||
| Machine weight | 8500kg | |||||||||
| Engine model | YUCHAI | |||||||||
| Rated Power | 48KW | |||||||||
| Rated Speed | 2200r/min | |||||||||
| Hydraulic system working pressure | 21Mpa | |||||||||
| Hydraulic system flow | 130L/min | |||||||||
| Variable piston pump | 65ml/r | |||||||||
| Max Hauling force | 60KN | |||||||||
| Walking speed | 25km/h | |||||||||
| Grade Climbing ability | 58%/30° | |||||||||
| Tyre model | 825.16 | |||||||||
| Volume Of Bucket | 0.25m3 | |||||||||
| Revolution Overdrive Pressure | 16Mpa | |||||||||
| Full circle swinging time | 5.5s | |||||||||
| Fqt Fuel Quantity | ≥4L/h | |||||||||
| Hydraulic Tank Capacity | 110L | |||||||||
| Capacity Of The Fuel Tank | 110L | |||||||||
