Model NO.
Railway Steel Sleepers
Concrete Grade
C60
Section Height
Sub-Rail 23.0/ Middle 18.5
Section Width
Sub-Rail 30.0/Middle 28.0
Keywords
Railway Sleeper
Used for
Mine
Character 1
Reproduced Machine with Central Not Back.
Character 2
Coal Mine Underground Scraper
Transport Package
Export Standard Carton Box/Wooden Box Package
Specification
Bs, ASTM and DIN, SGS. ISO. CE
Origin
Jining City, Shandong Province
HS Code
73029010
Production Capacity
1000PCS/Month
After-sales Service:
on Line or Video
Warranty:
1 Year
Customized:
Steel Sleeper
Certification:
CE
Type:
Sleeper
Reinforcing-Bar:
10 Dia.7,8 Dia7
Introduction of Great Quality Railway Steel Sleepers Steel Rail Track Sleeper
Railway sleepers are used for the railway laying and bedding. There are wooden sleepers; reinforced concrete sleepers; steel sleepers; compound Material sleepers etc.zmwm02Sleeper Dimension: 1300x215x5.7mm
Steel Plate Dimension: 100x250x5.7mm
Hole Diameter: 16mm
Hole to Hole Center Distance: 167mm
Shandong China Coal group mainly manufacture the concrete sleepers, wooden sleepers and steel sleepers. Our sleepers are well received by both the domestic market and other markets in the world.
Parameter of Great Quality Railway Steel Sleepers Steel Rail Track Sleeper
| Type | Reinforcing-bar | Concrete grade | Section height | Section width | Base area (cm2) | Weight (kg) | Length (cm) | |||
| Sub-rail | Middle | Ending | Sub-rail | Middle | ||||||
| I | 36 dia.3 | C48 | 20.2 | 16.5 | 29.45 | 27.5 | 25 | 6588 | 251 | 250 |
| II | 44 dia.3,4 dia.10 | C58 | 20.2 | 16.5 | 29.45 | 27.5 | 25 | 6588 | 251 | 250 |
| III | 10 dia.7, 8 dia7 | C60 | 23.0 | 18.5 | 30.0 | 28.0 | 7720 | 320 | 260 | |
Photos of Great Quality Railway Steel Sleepers Steel Rail Track Sleeper
