Model NO.
TE9.9D
Trademark
EARROW
Origin
Jinhua China
HS Code
8407210000
Production Capacity
15000units/Year
Type:
Stand up Bike
Size (Inch):
40*14*44
Main Material:
Aluminium Alloy
Wheel:
3
Transport Package:
Carton Box
Specification:
CE
Our advantage:
1, Most die casting parts and plastic parts are made by our own factory, assure the quality control
2, We have a special surface pretreatment production line, passivated surface made the parts & engine more durable, anti corrosion;
3, Our main engineers used to work in previous BRP Chinese subsidiary plant, we learn from BRP technology, our outboards are more quiet;
4, Color of top cover are one-step moulding technology instead of painting, more flexible and more corrosion resisting;
5, 99% spare parts are compatable with Yamaha spare parts, easy for maintenance
Our 4 stroke 6HP four stroke is one cylinder; 15HP 2 stroke is Yamaha Enduro type, which is more powerful,
Our future
Our company will insist on producting and researching in outboard motors, now Our propane motor is available!
Strict & military standard for key parts,likeCDI Charging coil/bearing/gears
Surface pretreatment production line learn from BRP(Johnson OBM) Which make our outboards surface/parts more durable,anti-corrosion
Our factory Specialized in outboards & spare parts for more than 8 years;
Earrow are first OBM supplier use Japan TK carburetor & SOLAS propeller on outboards in China;
Earrow 15/25/30HP are official brand for government rescue team.
Now Earrow outboards got very good feedback from African and South American market~
If you have interest, please do not hesitate to contact with us!
1, Most die casting parts and plastic parts are made by our own factory, assure the quality control
2, We have a special surface pretreatment production line, passivated surface made the parts & engine more durable, anti corrosion;
3, Our main engineers used to work in previous BRP Chinese subsidiary plant, we learn from BRP technology, our outboards are more quiet;
4, Color of top cover are one-step moulding technology instead of painting, more flexible and more corrosion resisting;
5, 99% spare parts are compatable with Yamaha spare parts, easy for maintenance
Our 4 stroke 6HP four stroke is one cylinder; 15HP 2 stroke is Yamaha Enduro type, which is more powerful,
Our future
Our company will insist on producting and researching in outboard motors, now Our propane motor is available!
Strict & military standard for key parts,likeCDI Charging coil/bearing/gears
Surface pretreatment production line learn from BRP(Johnson OBM) Which make our outboards surface/parts more durable,anti-corrosion
Our factory Specialized in outboards & spare parts for more than 8 years;
Earrow are first OBM supplier use Japan TK carburetor & SOLAS propeller on outboards in China;
Earrow 15/25/30HP are official brand for government rescue team.
Now Earrow outboards got very good feedback from African and South American market~
If you have interest, please do not hesitate to contact with us!
| Model | F2.5A | F4B | F5C | F6C | |||||||||||||||||
| Dimension | Overall length | 623mm (24.5in) | 750mm (29.5in) | 750mm (29.5in) | 750mm (29.5in) | ||||||||||||||||
| Overall width | 345mm (13.6 in) | 333mm (13.1in) | 333mm (13.1in) | 333mm (13.1in) | |||||||||||||||||
| Overall height S | 1021mm (40.2in) | 1040mm (40.29in) | 1040mm (40.29in) | 1040mm (40.29in) | |||||||||||||||||
| Overall height L | 1150mm (45.3in) | 1168mm (46in) | 1168mm (46in) | 1168mm (46in) | |||||||||||||||||
| Net weight (S/L) | 17KG | 27kg/ 28kg | 27kg/ 28kg | 27kg/ 28kg | |||||||||||||||||
| Gross weight (S/L) | 24KG | 35kg/ 36kg | 35kg/ 36kg | 35kg/ 36kg | |||||||||||||||||
| Package Size (S/L) | 111*44.5*49 cm³/ 124*44.5*49 cm³ | 115*45*57.5 cm³ / 128*45*57.5 cm³ | 115*45*57.5 cm³ / 128*45*57.5 cm³ | 115*45*57.5 cm³ / 128*45*57.5 cm³ | |||||||||||||||||
| Full Throttle Operating Range | 5250-5750 r/m | 4000-5000 r/m | 4500-5500 r/m | 4500-5500 r/m | |||||||||||||||||
| Maximum Output | 1.8kw/2.5hp | 2.9kw/4hp | 3.6kw/5hp | 4.4kw/6hp | |||||||||||||||||
| Idling Speed | 1900±100r/m | 1500±50r/m | 1500±50r/m | 1500±50r/m | |||||||||||||||||
| Type | Four Stroke | Four Stroke | Four Stroke | Four Stroke | |||||||||||||||||
| Displacement | 72cc | 139cc | 139cc | 139cc | |||||||||||||||||
| Bore×Stroke | 54.0×31.5 mm | 62×46mm | 62×46mm | 62×46mm | |||||||||||||||||
| Ignition System | TCI | CDI | CDI | CDI | |||||||||||||||||
| Spark Plug | NGK BR7HS-10 | NGK BR7HS-10 | NGK BR7HS-10 | NGK BR7HS-10 | |||||||||||||||||
| Spark Plug Gap | 0.6-0.7mm | 0.6-0.7mm | 0.6-0.7mm | 0.6-0.7mm | |||||||||||||||||
| Control System | Tiller Handle | Tiller Handle | Tiller Handle | Tiller Handle | |||||||||||||||||
| Starting System | Manual | Manual | Manual | Manual | |||||||||||||||||
| Starting Carburation System | Choke Valve | Choke Valve | Choke Valve | Choke Valve | |||||||||||||||||
| Gear Position | Forward-Neutral | Forward-Neutral-Reverse | Forward-Neutral-Reverse | Forward-Neutral-Reverse | |||||||||||||||||
| Gear Ratio | 2.08 (27:13) | 2.08 (27:13) | 2.08 (27:13) | 2.08 (27:13) | |||||||||||||||||
| Trim and Tilt System | Manual Tilt | Manual Tilt | Manual Tilt | Manual Tilt | |||||||||||||||||
| Recommended Fuel | Unleaded Gasoline | Unleaded Gasoline | Unleaded Gasoline | Unleaded Gasoline | |||||||||||||||||
| Gear Oil | 0.075L | 0.1L | 0.1L | 0.1L | |||||||||||||||||
| Fuel Tank Capacity | 0.9 L | 1.1L | 1.1L | 1.1L | |||||||||||||||||
