Model NO.
Skt90s
Drive Wheel
6×6
Engine Capacity
＜4L
Seats
6-9
Horsepower
150-250hp
Tire Certification
ECE, GCC, ISO, DOT
Tire Design
Radial
Dumping Type
Front Lifting Style
Condition
New
Axle
Pengxiang
Capacity
33/38m3
Displacement
12.54L
Engine Model
Wechai Wp13G530e310
Gearbox Type
Fast FC6a250dpr
Transport Package
Nude Picking
Specification
12337X3875X4319mm
Trademark
Acntruck
Origin
China
HS Code
8429521200
Production Capacity
1000 Units Per Month
After-sales Service:
Provided
Warranty:
1-2 Year
Transmission Type:
Automatic
Power:
Diesel
Load Capacity:
1-10t
Emission Standard:
Euro 3
Product Description
The new designed low-stress and high-strength frame effectively prevents the fatigue breakage of frame and redue the overall stress level by 51% compared with competing products.
The hydro-penumatic suspension tech,nology is applied to replace the traditional leaf spring structure, remarkably improve the life and comfort of the machine , thoroughly solve the frequent breakage problem of front suspension leaf springs in the industry, and promote the attendance rate of the machine. The hydro-pneumatic suspension features excellent shock-absorbing and damping performance to remarkably improve the load application of frame and prolong the life of frame.
Front oil and gas suspension, buffer, vibration reduction are significantly improved; Greatly reducing the impact force of the frame, cab and other heavy parts, reduce the occurrence of various faults, and extend the life of the vehicle;Thoroughly solve the fracture problem of front plate spring.
The vehicle steering is easier to solve the problem of heavy mechanical steering caused by heavy truck in the industry;Equipped with emergency steering, to solve the problem of steering failure after engine flame out or steering pump failure.
Solve the problem of severe power decline caused by thermal recession in the braking system of vehicles under heavy load downhill condition;To solve the problem that the brake system cannot meet the requirements of the working condition, the customer needs to install the brake spray to reduce the operating cost.
Engine Model | WP13G530E310 |
Total Power | 390kW |
Maximum Torque | 2300NM |
Number/Type Of Cylinders | 6-Cylinder/Inline |
Displacement | 12.54L |
Gearbox Type | FAST FC6A250DPR |
Automatic/Manual | Automatic |
Left/Right Hand Drive | Right /Left |
Axle | Pengxiang |
Capacity (Struck/Heaped) | 33/38m³ |
Load Weight | 60T |
Tyre | 16.00R25 Wire Tyre/Tubeless |
Lubrication System | Manual/Automatic |
Size | 9107x3660x4530mm |
Net Weight | 32T |
Maximum Gradeability | 30% |
Minimum Turning Radius | 11000mm |
