Model NO.
SY3208
Seats
≤5
Horsepower
150-250hp
Tire Certification
GCC, ISO, DOT, CCC
Tire Design
Bias
Dumping Type
Front Lifting Style
Condition
New
Curb Weight
9200kg
Dumper Box
5600*2300*1200,1500mm
Max Loading Capacity
15t ~ 20t
Thickness
Side 4mm , Bottom 6mm
Lifting Style
Front Lifting , Optional Middle Lifting
Tire
10.00-20 / 11.00r20
Engine
155kw / 210HP Cummins Engine
Gear Box
Fast 8-Speed
Fuel Tank
200L
Transport Package
After Waxing by Container, RO -RO, Bulk Freighter
Specification
8300*2500*3350mm
Trademark
SUNY
Origin
China
HS Code
8704230090
Production Capacity
2000 Units / Years
Transmission Type:
Manual
Power:
Diesel
Load Capacity:
11-20t
Emission Standard:
Euro 2
Drive Wheel:
6×4
Engine Capacity:
4-6L
Dump truck is widely used in transporting the construction material, such as sand, stone, gravel, coal, earthwork etc.Main configuration: hydraulic system, which brand HYVA or Chinese top brandMain material: carbon steel, high-strengthen steel T700/T750 Lifting system: middle lifting, front lifting Hydraulic system: HYVA, PERMCO, Chinese brandTipping box shape: rectangle, U-shape
| Vehicle Description | |
| Overall dimensions | 8300*2500*3350mm |
| GVW | 25000kg |
| Curb weight | 9200kg |
| Chassis brand | DONGFENG 3208 |
| Traction type | 6*4 |
| Up-parts Description | ||
| Cargo dimension | 5600*2300*1200,1500mm | |
| Loading capacity | 15-20T | |
| Material | Carbon steel | |
| Thickness | Side | 6mm, 8mm, 10mm |
| Bottom | 8mm, 10mm,12mm | |
| Hydraulic system | Imported or Chinese brand | |
| Lifting style | Front or middle lifting | |
| Chassis Description | ||
| Chassis model | EQ3208 | |
| Cab | Flat-roof, half row | |
| Wheelbase | 3500+1350mm | |
| Tire specification | 10.00-20 | |
| Tire quantity | 10+1 units | |
| Engine | Engine model | B210 33 |
| Emission level | Euro 2 | |
| Displacement/output | 5900ml/155kw | |
| Horse power | 210hp | |
| Gear box | Type | 8-speed |
| Number of gears | 8 forward gears & 1 reverse | |
| Brake system | Full air brake system | |
| Axle | Front | 5T |
| Rear | 10T*2 | |
| Suspension | Front | Leaf springs, with shock absorber |
| Rear | Leaf springs | |
| Fuel tanker | Type | Steel tanker, with lockable cap |
| Capacity | 200L | |
Producing details:
