Model NO.
ZZ3257N3847A
Drive Wheel
6×4
Engine Capacity
＞8L
Seats
6-9
Horsepower
351-450hp
Tire Certification
ISO
Tire Design
Tubeless
Dumping Type
Bidirection Dumping Style
Condition
New
Transport Package
Nude Package
Specification
8600*2600*3450mm
Trademark
HOWO
Origin
China
HS Code
8704103000
Production Capacity
500/Month
After-sales Service:
Field Maintenance and Repair Service
Warranty:
1 Year Warranty
Transmission Type:
Manual
Power:
Diesel
Load Capacity:
21-30t
Emission Standard:
Euro 2
Low Price Chinese Best Selling Sinotruck HOWO 6X4 dump Truck tipper truck 10 Tyre Made In China
Dump truck is mainly used for transportation of dumps, such as sand and stone, which is common in construction work.
Cabin: HW76 cabin, with one sleeper (berth), Air-conditioner, MP3, safety belts, adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers, etc.
Transmission: HW19710, 10 F and 2 R, manual.
Transmission with main and auxiliary transmission structure, main transmission with double counter shaft, auxiliary transmission with planetary reduction.
| Item | SINOTRUK HOWO 6x4 25ton Dump truck |
| Model | ZZ3257N3847A |
| Color | Optional (Red, White, Yellow, Blue) |
| Driving type | LHD/RHD |
| Engine | Make: SINOTRUK Engine model: WD615.47, 371hp, Euro 2 6-cylinder in-line with water cooling, turbo-charging and intercooling. Rated Power (kw/rpm): 273/2200 Maximum Torque (Nm): 1500N.m Maximum Torque speed: 1100~1600RPM Displacement: 9.726 L |
| Steering | ZF8118 power steering with hydraulic system. |
| Front Axle | Heavy duty axle, 9000kgX1, drum brake. |
| Rear Axles | Heavy duty axle,16000kgX2. Speed ration: 4.42;4.8;5.73 |
| Wheelbase (mm) | 3825+1350 |
| Front/Rear overhang (mm) | 1500/1670 |
| Wheel track (front/rear) mm | 2022/1830 |
| Minimum ground clearance (mm) | 314 |
| Approach/departure angle (°) | 16/25 |
| Braking System | Service brake: dual circuit compressed air brake Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels Auxiliary brake: engine exhaust brake |
| Electrical System | Voltage: 24 V Generator: 1540W Starter: 24 V, 7.5 Kw Batteries: 12V/165Ah, 2 pieces Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light |
| Tire | 12.00R20, radial steel tire, plus one spare tire (11 units) |
| Fuel tank | 300L volume |
| Tipper box (mm) | 5600X2300X1500 ( 19 m3) Ventral lifting, strengthen model. |
| External dimension | 8600x 2600x3450 mm |
