| Parameter |
Cab | F3000 Cab,Single bed,Air conditioner |
Dimension(Lx W xH)(mm) | 10329×2500×3450mm |
Total mass(kg) | 31000kg |
Kerb mass(kg) | 14600kg |
Rated mass(kg) | 15930kg |
Payload(kg) | 40000kg |
Approach / departure angel | 28/21 |
Front/rear suspension(mm) | 14525/2029 |
Max. gradeability (%) | 28 |
Engine brand | Weichai Engine |
Engine model | WP10.340E32,340hp |
Rated output power | 250kw |
Torque(N.m r. p. m) | 1250N.m/1200-1600rpm |
Rated speed(rpm) | 2200rpm |
Emission Standard | E-II |
Fuel type | Diesel |
Displacement(L) | 9.726L |
Driving type | 8×4 |
Axle number | 4 |
Wheel base(mm) | 1800+3575+1400mm |
Clutch | φ430 diaphragm spring |
Gearbox | FAST 10JSD140,10 Forward&2 Reverse,Manual |
PTO | QH50 |
Front axle | 7.5T MAN 2×7500kg |
Rear axle | 16T MAN 2×16000kg |
Ratio | 5.262 |
Steering | Z F technology left-hand drive(LHD) |
Type | 12.00R20,12+1pc |
Tank capacity(L) | 380L |
Max. speed (km/h) | 82km/h |
Color | Optional |
Cargo box size(mm) | 7400×2300×1500mm bottom10mm,side8mm |
Lifting style | Front lifting(made in china) |
| Product Show |
| Company Information |
Oriemac Machinery & Equipment (Shanghai) Co., Ltd.
Oriemac is a leading Chinese construction machinery exporter, located in Shanghai, and has introduced top Chinese machinery enterprises and their products to international markets.
Oriemac brings you a wide range of construction machionery series as follows:
-- Lifting Machinery, such as Truck Crane, All Terrain Crane, Rough Terrain Crane, Crawler Crane, and Truck-mounted Crane-- Earthmoving Machinery, such as Wheel loader, Mini Loader, Excavator, Bulldozer, Backhoe Loader, and Skid Steer Loader
-- Concrete Machinery, such as Concrete Pump, Trailer-mounted Concrete Pump and Concrete Mixer
-- Drilling Machinery, such as Horizontal Directional Drill, Rotary Drilling Rig and Roadheader
-- Logistics Machinery, such as Telescopic Handler and Forklift
-- Special Vehicle, such as Dump Truck, Semi Trailer, Aerial Work Form, and Fire Truck
