Model NO.
F3000
Seats
≤5
Horsepower
351-450hp
Tire Certification
ECE, GCC, ISO, DOT
Tire Design
Radial
Dumping Type
Front Lifting Style
Condition
New
Wheel Base
1800+3575+1400mm
Cargo Box Size
7400X2300X1500mm
Engine
Weichai or Cummins
Gearbox
Fast
Front Axle
Man
Steering
Zf
Transport Package
Nude Packing
Specification
8329x2500x3450mm
Trademark
SHACMAN
Origin
China
HS Code
84291190
Production Capacity
100 Sets/Month
Transmission Type:
Manual
Power:
Diesel
Load Capacity:
21-30t
Emission Standard:
Euro 3
Drive Wheel:
8×4
Engine Capacity:
＞8L
SHACMAN F3000 8×4 DUMP TRUCK
Engine details:
Brand & Model: WP10.380E22,380hp
Rated power: 280kW (380hp)
No. Cylinders: 6
Torque: 1250N.m/1400-1600rpm
Displacement: 9.726L
Water-cooled, four-stroke, with exhaust valve brake, direct injection, supercharged intercooler
Gearbox details:
FAST 10JSD180,10 Forward&2Reverse,Manual
Front Axle:
9.5T MAN,with drum braking system
Rear Axle:
16T MAN double speed reduction drive axle
Cargo box:
25m3
7400×2300×1500mm
bottom10mm; side8mm
| Cab | MAN F3000 Cab,Single bed,NoA/C |
| Dimension(Lx W xH)(mm) | 10435×2500×3450mm |
| GVW (kg) | ≤65000kg |
| Kerb mass(kg) | 14600kg |
| Approach / departure angel | 28/20 |
| Front/rear suspension(mm) | 1525/2060 |
| Max.gradeability(%) | 28 |
| Enginebrand | Weichai Engine |
| Engine model | WP10.380E22,380hp |
| Rated output power | 280kw |
| Emission Standard | E-II |
| Displacement(L) | 9.726L |
| Driving type | 8×4 |
| Axle number | 4 |
| Wheel base(mm) | 1800+3575+1400mm |
| Clutch | φ430diaphragm spring |
| Gearbox | FAST 10JSD180,10 Forward&2Reverse,Manual |
| PTO | QH50 |
| Front axle | 9.5T MAN,with drum braking system |
| Rear axle | 16T MAN double speed reduction drive axle |
| Steering | ZFtechnologyright-hand drive(RHD) |
| Type | 12.00R20,12+1pc |
| Suspension | Both front and rear are high strengthen mechanical leaf spring+4 U bolts |
| Tank capacity(L) | 400L |
| Max. speed (km/h) | 80km/h |
| Color | Optional |
| Cargo box size(mm) | 7400×2300×1500mm bottom10mm,side8mm |
| Lifting style | φ200 hydraulic frontlifting cylinder |
Photos:
