*China famous brand Howo Mobile Diesel Fuel Dispenser Truck with 8m3/8cbm/8000L Oil Tanker Truck*
Our factory is professional manufacturer in truck area,
guarantee all products Brand-New and High-Quality.
» I.Product Describution:
Manufacturer: Hubei Manten Automobile Co.,Ltd.
Features:1.Tank material : 4-6mm thick carbon steel with high quality .
carbon steel and stainless steel or aluminum alloy can be choose.
2.Tank shape: square-round, oval, round.
3. Pump : can be choose self-priming pump, gear pump or double pump;
the pump can help the oil pump in and out or self-flow.
4.Special design: can be designed to an independent sub-warehouse to transport different oil with the same time.
15 meters refueling reel (can automatically return to position),
the tank is equipped with many anti-wave boards to keep the tank with high strength, stable center of gravity,
delivery safety and other characteristics in the transportation.
» II.Product Parameter:
| Howo 10,000L Fuel Tank Truck | |
| Chassis | |
| Chassis model | ZZ1127G4715C1 |
| Overall dimensions | 8445*2400×2650mm |
| Wheel base | 4700mm |
| Driving type | 4×2 |
| Approach/departure angle | 1 11/16 |
| Front /rear overhang(mm) | 1240/2505 |
| Wheel track(frontrear)(mm) | 1798/1764 |
| Engine model | YC4E160-33 |
| Engine manufacturer | Yuchai |
| Engine power | 160HP |
| Engine Cylinder number | 4cylinders in-line,4-strokes, water-cooled |
| Emission standard | Euro 3 |
| Displacement | 4260 ml |
| Steering | Left drive hand |
| Transmission | DC6J65TC,Manual,6 Forwards and 1 Reverse |
| Tyre size | 8.25R20 |
| Tyre number | (6+1)one spare tire |
| Axle (front'rear) | 3.2T/8T |
| Max driving speed(km/h) | 95 |
| Fuel tank | |
| Capacity | 6,000 liters |
| Material | Q2358 carbon steel,epoxy paint 3 layer inner surface for anti-corrosion |
| Shape of tank | Elliptic |
| Manhole cover | European standard manhole with breather valve |
| Outlet and inlet | 1 pcs outlet and 1 pcs inlet |
| Tank Thickness(mm) | 5mm |
| Compartment | with two compartments |
| Safety Valve | European Standard,1pcs |
| Discharge valve | luminiumAlloy Ball Valve type(stainless steel ball valve is optional) |
| Emergency Cutoff Device | Equlpped,1pcs |
| Pump | Equlpped.1pcs |
| Flow Meter | Equipped,1pcs |
| Dispenser | CENSTAR(most famous Chinese brand) with 15M rotary filling gun |
| Standard | tool box,climbing ladder,handrail, fire extinguisher, oil hose etc are included |
| Ladder | at rear of tank |
| Painting | Color and design as customer's requirement |
Fuel truck also known as oil tank truck,fuel tank truck, fuel dispenser truck ,mobile refueling truck, oil transport vehicle,mobile catering truck,mobile refueling truck, oil tanker, oil loading truck, fuel bowser truck,oil tanker, fuel tank truck, oil bowser, fuel oil tanker,oil delivery truck, petroleum service truck, fuel oil storage tank, fuel tanker lorry, refueling tanker truck, crude oil truck,mainly used for the transportation and storage of petroleum derivatives (gasoline, diesel, crude oil, lubricating oil, coal tar and other oils).
-----Tanker material:Carbon steel, stainless steel, lined with rubber, aluminum tank
» III.Product Details:
1. Independent two compartments:
This Refueling truck adopts Sinotruk HOWO chassis , 10000Liters Fuel Tank ,equipped with 2 compartments,for 2 diffrent kind oil.
2.Tank innner body treatment:
The tank body is made of Q235B carbon steel.The tank innner body shall be treated with rust prevention and oil coating.
3.With fuel dispenser and refueling reel and gun,can be measured and easy to use.
Products--100% First Class!
Transportation--100% Convenience, Efficient!
Services--Obtaining a satisfied smile!
1.we can do the designs according to the your requirement .
2.we can offer you the high quality & reasionalble price
3.we can offer your a good after-sell service
4.we have strong professinal design team
5.promptly delivery. any order is welcome.
We also supply spare parts (original, OEM, and replacement) for all types of trucks and trailers
with discount and nice quality to ensure our customers's trucks and trailers being in good working conditions.
» IV.Company Intorduce:
» V. Professional packing and transprotation:
- Thick wax polished on products before shipping to protect.
- Use container, RORO/bulk ship or others as your requirement.
- We provide transportation insurance to guarantee the new and great condition of products for customers.
YOU ARE ALWAYS WELCOMED TO VISIT OUR FACTORY!
