Model NO.
shacman cargo truck chassis
Seats
≤5
Horsepower
251-350hp
Engine Capacity
＞8L
Tire Certification
ECE, GCC, ISO, DOT
Tire Design
Radial
Condition
New
Cabin
with A/C & Sleeping Bed
Engine
Weichai Brand
Engine Optional
336HP, 340HP, 375HP, 380HP
Emission Optional
Euro 2, 3, 4
Axle
Man Axles
Steering
Zf Technology
Tire
12.00r20, Radial Tires
Colors
Red, White, Blue, etc
Transport Package
Nuding
Specification
8x4 cargo truck
Trademark
Shacman F3000
Origin
Shaanxi, China
Production Capacity
10000 Sets/Year
Type:
Rack-body Style
Transmission Type:
Manual
Emission Standard:
Euro 3
Load Capacity:
21-30t
Power:
Diesel
Drive Wheel:
8×4
| China Top Brand -- Dawnshine |
| Shacman F3000 8x4 12wheels 336hp Cargo Lorry Truck Chassis |
 |
| Parameters | |
| Drive Type | 8x4 |
| Cab | |
| Type | F3000 Cabin |
| Equipment | with Air Condition,One sleeper |
| Weight | |
| Kerb mass(kg) | 13240 |
| GVW(kg) | 13240+25000 |
| Dimensions | |
| Max. length(mm) | 9130 |
| Max. width(mm) | 2500 |
| Max. height(mm) | 3950 |
| Front/Rear overhang(chassis) | 1525/2055 |
| Wheel base(mm) | |
| Track width(mm) | 2036/1808 |
| Steel (mm) | 5mm |
| Performance | |
| Max. speed (km/h) | 90 |
| Max. gradeability(%) | 30 |
| Approach/Departure angel(°) | 20/19 |
| Engine | |
| Brand | WEICHAI |
| Model | WP10/12 |
| Power (kw/hp) | 336hp-420hp |
| Max torque (N.M)/rpm | 1360/1400--1600 |
| Displacement (L) | 9.726/11.596 |
| Emission Standards | Euro II/III |
| Transmission | |
| Brand | FAST |
| Model | 12JS160T |
| Control type | Manual |
| Gear Shift | 12-forward & 2-reverse speeds |
| Clutch | Single plate,diaphragm spring |
| Diameter (mm) | Φ430 |
| Action | Hydraulically operating with air assistance |
| Brakes | Drum |
| Service Brake | With dual-circuit compressed air brake |
| Park Brake | Power spring brake acting on rear wheel |
| Auxiliary Brake | WEVB |
| Steering | ZF Technology |
| Suspension | |
| Front | Longitudinal leaf spring |
| Rear | Inverted leaf spring stabilizator suspension |
| Axles | |
| Front | MAN : 6.5 ton |
| Rear | MAN : 13ton |
| Ratio | 4.7/5.2/5.9 |
| Tyre | 12.00R20/22.5 |
| Fuel Tank | 300/400L |
| Material | Aluminium Alloy |
| Electrics | |
| Type | 24V |
| Starter | 5.58kw(24) |
| Generator | 2.0kw(28V 70A) |
| Battery | 2x135Ah |
| Features |
  |
