Model NO.
K01S
Seats
≤5
Horsepower
＜150hp
Engine Capacity
4-6L
Tire Certification
ISO
Tire Design
Radial
Condition
New
Color
White
Code
Confortable
Transport Package
Nude
Specification
3970*1560*1825mm
Trademark
Dongfeng
Origin
China
HS Code
8702903000
Production Capacity
1000units/Month
Type:
Flatbed Style
Transmission Type:
Manual
Emission Standard:
Euro 3
Load Capacity:
1-10t
Power:
Gasoline
Drive Wheel:
4×2
K01S Specifications
| Dongfeng K01S Model Parameter | ||
| Specification Details: | ||
| Dimension&Mass | ||
| L*W*H (mm) | 3970×1560×1825 | 4435×1560×1825 |
| Cargo Size(mm) | 2300×1500×340 | 2700×1500×340 |
| Wheelbase (mm) | 2515 | 2760 |
| Tread(Front/Rear) (mm) | 1310/1310 | |
| Curb Weight(kg) | 880 | |
| Gross Weight(kg) | 1920 | |
| Seats | 2 | |
| Min.turning diameter (m) | ≤9.8 | |
| Max.gradeability(%) | ≥30 | |
| Engine | ||
| Engine Model | AF11-05 | DK12-01 |
| Engine Position | Middle Positioned | |
| Engine Type | Four Cylinders in Line, Four-strokes, Water Cooling, DOHC, Petrol Engine With Electric Control Fuel Injection. | |
| Emission standard | National Standard IV /Euro 5B+ | |
| Displacement (cc) | 1050 | 1206 |
| Power (kw) | 47 | 64 |
| Max torque (N.m) | 91 | 108.5 |
| Fuel Tank Capacity (L) | 40 | |
| Gear Box | 5 MT | |
| Max Speed(km/h) | 110 | 115 |
| Fuel Consumption(L/100km) | 7.1 | 7.5 |
| Chassis | ||
| Braking System | Front disk & Rear drum, Dual Circuit Hydraulic Braking System | |
| Driving Model | Rear-wheel drive | |
| Front/Rear Suspension | Macpherson Independent Suspension, Five-bar Rear Semi-independent Suspension. | |
