5cbm 5000liters 2mt 3tons FAW 4X2 LPG bobtail Tanker Truck with dispenser for refilling cylinders
Product Description
Liquefied petroleum gas (LPG) is a by-product of oil and gas fields, petroleum distillation and chemical production. It is composed of a variety of hydrocarbons, mainly by propane, butane, propylene, butene and other low molecular hydrocarbon mixture, also contains a small amount of impurities, commonly known as carbon three carbon four. Liquefied petroleum gas, abbreviated as LPG, is a liquid mixture of propane (C3H8) and butane (C4H10) as the main components, which is gaseous at room temperature and pressure and usually stored under pressure or low temperature. It is usually accompanied by a small amount of propylene (C3H6) and butene (C4H8), as well as trace amounts of alkane (C5H12) and pentene (C5H) 10) and other components, is a kind of clean gas energy, mainly used for catering, civil and industrial and commercial combustion demand, such as gasoline additives, synthetic plastics, rubber, fiber and the production of medicine, explosives and other chemical deep processing demand.
Pressure vessel is internal or external under gas or liquid pressure, and has higher requirements for safety of the sealed container.
Pressure vessels are mainly cylindrical, and a few are spherical or other shapes. Cylindrical pressure vessel is usually composed of cylinder body, head, pipe, flange and other parts and components, the higher the pressure of the pressure vessel, the thicker the wall of the cylinder body should be. Storage pressure vessel (code C, including spherical tank code B) : used for storing and containing gas, liquid, liquefied gas and other media.
1. Storage medium of LPG bobtail truck : LPG, Liquid ammoina,Dimethyl ether,Iso-butane,Pentane and etc.
2. Truck Brand of LPG Gas Bobtail : Howo,optional for dongfeng,faw,foton and other brands
3. Available tank capacity of LPG bobtail truck: 5m³, 5.5m³, 8m³, 10m³, 12m³, 15m³, 16m³, 18m³, 20m³, 24m³, 25m³,35.5m³,37.2m³
4. Function of LPG Gas Bobtail : mobile Propane or Butan Gas Delivery/ Refilling/bottling/filling
5. Manufacturing standards of LPG bobtail truck: GB-150, ASME VIII Division I U STAMP, CCC, ISO9001 : 2008
6. Refiling System of LPG Gas Bobtail: 2" Flowmeter or intelligent filling dispenser machine,2" Corken or Chinese brand Pump,15meters Filling Hose Reel
Specification
| Main Technical Parameter | |
| Model Name | FAW 4x2 5000Liters LPG bobtail truck with dispenser |
| Driving Type | 4x2,left hand drive or right hand drive |
| Weights | |
| Rated payload weight(kg) | 5000 |
| Curb weight(kg) | 4990 |
| Dimensions | |
| Wheelbase(mm) | 3360 |
| Overall Dimension(mm) | 5900×2145×2600 |
| Tank volume | 5000L |
| Max speed(km/h) | 90 |
| Engine | |
| Engine model | CA498E3-12 120HP |
| Engine type | Diesel 4-storke, Inter-cooling,water-cooling |
| No. of cylinders | straight-4 cylinders |
| Displacement(ml) | 3168 |
| Rated power Rev((Kw) | 90kw |
| Drive Line | |
| Transmission | 6 speeds, 6 forwards, 1 reverse gear,manual operation |
| Brake system | Air break |
| Cab | |
| cabin | FAW |
| Axle | |
| Front axle | 2.5 tons |
| Rear axle | 4.5 tons |
| Tire specification | |
| Tire specification | 7.00R16 standard tire |
| Tire quality | 6 tires+1 spare tire |
| Other | |
| Electric system | 24V |
| Tool | Standard equipment |
| Configuration | |
| Tanker material | Q345R 10mm |
| Others | Storage for:liquified propane |
| design pressure 1.77Mpa; | |
| design temperature 50 ; | |
| filling density: 0.42T/M3; | |
| corrosion allowance: 1mm; | |
| with dispenser for refilling cylinders | |
| Industry Protocol | GB150-1998 "Steel Pressure Vessels," Pressure Vessel Safety technical monitoring procedures, LPG safety inspection procedure |
Factory overview
Production Process of Propane Gas Storage Tank
Customer Inspection
Overseas Exhibition and After-sales Service
Warranty
1. One year free warranty for major 3 components of our trucks: engine, gearbox, axles.
2. We offer video guidance and our engineers will go to customer's country to assist the installation and operation when quantity reaches 20 units.
3. Transportation warranty: our company offers transportation insurance for customer to ensure the products arriving at destination safely.
Spare Parts
1. Supplying quick-wearing parts at the truck delivery.
2. Good quality parts produced by the truck manufacturing factory.
3. Only charge cost price for customer convenience.
After Sales Service
Email & Phone call tracking for each truck on timely manners.
Shipment
Land transportation or Ship by bulk cargo ship, container, roro ship
