Model NO.
Tanker Truck
Seats
≤5
Horsepower
351-450hp
Engine Capacity
4-6L
Storage
Oil
Tire Certification
ISO
Tire Design
Tubeless
Condition
New
Cab Type
One and a Half Cabin, with a Sleeper
Tanker Capacity
30 Cbm
Rated Payload
15740kg
Max Speed
80km/H
Tyre Type
295/80r22.5 18pr Steel Wire Tire
Braking System
Air Brake
Transport Package
Nude Package
Specification
9000mm*2200mm*1500mm
Production Capacity
3000
Transmission Type:
Manual
Power:
Diesel
Load Capacity:
21-30t
Emission Standard:
Euro 5
Tank Volume:
5001-10000L
Drive Wheel:
6×4
30cbm Oil Delivery Tanker Truck 8*4 Gasoline Petroleum Diesel Tanker Truck
| Braking system | Air brake |
| Electrical system | 24 voltage,7 wire harness,LED lights. |
| Painting | With shot blasting and 4 layers painting,color is optional. |
| Packing | Nude,polish with wax before shipment. |
Remark | The above mentioned data is for your reference only. The detailed specification will be subject to our final confirmation. |
| Product Details | |
| Chassis brand | DF |
| Drive form | LHD or RHD optional |
| Emission standard | Euro 2/3/4/5 optional |
| Drive model | 8×4 |
| Drive form | LHD or RHD optional |
| Fuel type | Diesel |
| Cab type | One and a half cabin ,With a sleeper(Flat top cab or high top cab) |
| Overall dimension | 11800mm×2500mm×3400mm |
| Tanker dimension | 9000mm×2200mm×1500mm |
| Tanker capacity | 30 CBM |
| Tanker material | Carbon steel,Aluminum alloy ,Stainless steel , material optional |
| Engine brand | CUMMINS,YUCHAI,CHAOCHAI, |
| Engine model | ISL9.5-315E51A-50 30/33/40 optional |
| Horsepower | 315hp |
| Displacement | 9460ml/ |
| Emission standard | Euro 2/3/4/5 |
| Tare weight | 15130kg |
| Rated payload | 15740kg |
| Wheelbase | 2050mm+4000mm+1350mm |
| Max speed | 80km/h |
| Tyre type | 295/80R22.5 18PR steel wire tire |
| Tyre number | 12 (with a spare tire ) |
| Transport medium | Gasoline, diesel ,kerosene, |
