Model NO.
ZZ3257N4347W
Drive Wheel
6×4
Seats
≤5
Horsepower
251-350hp
Engine Capacity
＞8L
Tire Certification
ECE, GCC, ISO, DOT
Tire Design
Radial
Condition
New
Color
as Customers Option
Transport Package
Nude Look
Specification
Heavy Truck
Trademark
SINOTURK
Origin
China
HS Code
8601101100
Production Capacity
3000units/Month
After-sales Service:
24 Hours Online Service
Warranty:
6-12 Months
Transmission Type:
Manual
Power:
Diesel
Load Capacity:
31-40t
Emission Standard:
Euro 2
| Truck Model | ZZ4257N3241W (Left Hand Drive) | |||
| Dimension(Lx W xH)(mm) | 8545, 8614x2496x 3450 | |||
| Approaching angle/Departure angle(°) | 16/70 | |||
| Overhang(front/rear) (mm) | 1500/700,725 | |||
| Wheel base (mm) | 3200+1400,3225+1350 | |||
| Max speed(km/h) | 102 | |||
| Curb weight(kg) | 11930 | |||
| Max Loading Weight(kg) | 60000 | |||
| Engine (Steyr technology, made in China) | Model | WD615.69/47,water-cooled, four strokes,6 cylinders in line with water cooling, turbocharged and intercooling, directly injection | ||
| Fuel type | Diesel | |||
| Horse power | 336/371hp | |||
| Emission | EURO2 | |||
| Fuel tanker capacity(L) | 400 | |||
| Transmission | Gearbox: | HW19710, 10 forward & 2 reverse | ||
| Brake system | Service brake | Dual circuit compressed air brake | ||
| Parking brake | spring energy, compressed air operating on rear wheels | |||
| Steering system | Model | ZF8118 | ||
| Front axle: | HF7, 7000KG | |||
| Rear axle | ST 16,double reductions, 16000KG*2 | |||
| Color | Green . | |||
| Tyre | 12.00R20,11pcs with one spare and one carrier | |||
| King Pin/Fifth wheel: | 90# 3.5inch | |||
| Electrical system | Battery | 2X12V/165Ah | ||
| Alternator | 28V-1500kw | |||
| Starter | 7.5Kw/24V | |||
| Cab | HOWO76 cab, (one sleeping, with air-condition), all-steel forward control, 55ºhydraulically tiltable to the front, 2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver's seat and rigid adjustable co-driver's seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers. | |||
