Model NO.
ZZ3317M3867W
Drive Wheel
8×4
Engine Capacity
＞8L
Seats
≤5
Horsepower
351-450hp
Tire Certification
ISO
Tire Design
Radial
Dumping Type
Front Lifting Style
Condition
New
Overall Dimension(L*W*H)
10745*2496*3386
Rear Axle Ratio
5.73
Front Axle
Hf9
Gross Vehicle Weight
31000
Place of Origin
Shandong, China (Mainland)
Dimension of Cargo Box(L*W*H)Mm Cargo
7800*2300*1500 26.9 Cbm
Transport Package
in Nude
Specification
CE and so on
Trademark
sinotruk howo dump truck
Origin
Shandong China
HS Code
8704230090
Production Capacity
1000piece/Month
After-sales Service:
Yes
Warranty:
Yes
Transmission Type:
Manual
Power:
Diesel
Load Capacity:
41-50t
Emission Standard:
Euro 2
Advantages:
1)IS9000 and TS16949 certificate
2)High quality and competitive
3)Professional technology
4)HC16 driving axles
5)Four channel ABS of WBACO
Details:
Cab: Long cab HW76, all-steel forward control, 2-arm windscreen wiper system with three speeds, laminatedwindscreen with casted-in radio aerial, hydraulically damped adjustable driver's seat and rigid adjustable co-driver's seat, with heating and ventilating system( Option: HW70 Economical cab/ HW79 high roof cab);
Steering: power steering, model 8098, hydraulic steering with powerful assistance;
Engine: Electronic control EGR system( COMMON RAIL ENGINE is alternative)/336HP,375HP
Clutch: Single-plate dry coil-spring clutch;
Suspension: Multiple-leaf suspension,( HUV rubber suspension can be chosen--load capacity 27.6 tons, Weight light, reducing weight effectively);
Tyres: Bias tyre,( tubeless tyre and radial tyre can be chosen )
Transmission: HW13710 ( over-drive transmission can be chosen )
Front axle: HF7 disc brake ( drum brake is alternative)
1)IS9000 and TS16949 certificate
2)High quality and competitive
3)Professional technology
4)HC16 driving axles
5)Four channel ABS of WBACO
Details:
Cab: Long cab HW76, all-steel forward control, 2-arm windscreen wiper system with three speeds, laminatedwindscreen with casted-in radio aerial, hydraulically damped adjustable driver's seat and rigid adjustable co-driver's seat, with heating and ventilating system( Option: HW70 Economical cab/ HW79 high roof cab);
Steering: power steering, model 8098, hydraulic steering with powerful assistance;
Engine: Electronic control EGR system( COMMON RAIL ENGINE is alternative)/336HP,375HP
Clutch: Single-plate dry coil-spring clutch;
Suspension: Multiple-leaf suspension,( HUV rubber suspension can be chosen--load capacity 27.6 tons, Weight light, reducing weight effectively);
Tyres: Bias tyre,( tubeless tyre and radial tyre can be chosen )
Transmission: HW13710 ( over-drive transmission can be chosen )
Front axle: HF7 disc brake ( drum brake is alternative)
| Product Information | ||
| Product | Howo 8x4 Dump Truck | |
| Brand Name | SINOTRUK-HOWO | |
| Chassis Model | ZZ3317N3867C1 | |
| Place of Origin | Jinan, China | |
| Color | Any color will be available | |
| Manufacture | China National Heavy Duty Truck Group Co., Ltd. | |
| Product Specifications | ||
| Engine model | WD615.95C, water-cooled , four strokes , 6 cylinders in line with water cooling , turbocharged and intercooling, directly injection | |
| Engine Power | 340HP | |
| Emission standard | Euro III | |
| Overall dimension(L*W*H) | 10745*2496*3450 | |
| Dimension of Cargo Box(L*W*H)mm Cargo body dimension | 7800*2300*1500 26.9 cbm Bottom: 8mm Side: 6mm | |
| Lift type of carriage | Front Lift | |
| Wheelbase | 1800+3800+1350 | |
| Overhang (front/rear)mm | 1500/2725 | |
| Approachingangle/Departrue angle ( ° ) | 19/14 | |
| Vehicle gross weight(kg) | 31000 | |
| Curb weight(kg) | 15500 | |
| Max speed(km/h) | 75 | |
| Fuel tank capacity(L) | 300 | |
| Fuel type | Diesel | |
| Transmission model | HW19710 10 froward and 2 reverse | |
| Steering system | ZF8098 | |
| Front axle | HF9 Steering with double T-cross section beam | |
| Rear axle | HC16 casting axle housing, central double reduction with differential locks between axles and wheels | |
| Tire | 12.00-20 Radial Tire | |
| Color | Optional | |
| Brake system | Service brake | Dual circuit compressed air brake |
| Parking brake | Spring energy, compressed air operating on rear wheels | |
| Auxiliary brake | Engine exhaust brake | |
| Electrical system | Battery | 2X12V/165Ah |
| Alternator | 28V-1500kw | |
| Starter | 7.5Kw/24V | |
| Cab | HW76 cab, (one sleeper, with air-condition), all-steel forward control,55ºhydraulically tiltable to the front, 2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver's seat and rigid adjustable co-driver's seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers. | |
