Model NO.
SX3316DV366
Drive Wheel
8×4
Engine Capacity
＞8L
Seats
≤5
Horsepower
351-450hp
Tire Certification
GCC, ISO
Tire Design
Tubeless
Dumping Type
Front Lifting Style
Condition
New
Engine Model
Wd615 Engine/D10engine/D12 Engine
Color
Customer′s Request
Tire
12.00r20
Driving Type
LHD
Transport Package
in Nude
Specification
8275*2500*3450mm
Trademark
SHACMAN
Origin
Shaanxi
Production Capacity
500
shacman f3000 8x4 dump truck
Product overview:
Detail pictures:
Detail pictures:Traction type | 8×4 | |
Drive System | LHD/RHD | |
Cabin | F2000 flat Cabin, one sleeper, Air Conditioner | |
Engine | Brand | WEICHAI |
Model | WD615.50 EURII | |
Rated power | 290hp | |
Engine displacement | 9.726 liters | |
Gearbox | FAST 9 Speeds (9JS135) | |
Clutch | 430 Diaphragm type | |
Steering | Power steering | |
Axle | Front | 7.5 Ton MAN-axle |
Rear | 13 Ton STR double reduction axle, ratio:5.73 | |
Max. running speed (km/h) | 77 | |
Tire/number | 12.00R20/10+1 | |
Fuel tank | 380L | |
Kerb weight (kg) | 11200 | |
Total mass (kg) | 25000 | |
Wheel base (mm) | 3800+1350 | |
Overhang (mm) (front/rear) | 1525 / 1600 | |
Track (mm) (front/rear) | 1939/1800 | |
Approach / departure angle(°) | 16/66 | |
Dump body | Size(L*W*H) | 5200x2300x1500 (18 m3) |
Thickness | Bottom 8, front 6, side 4 | |
Lifting system | Middle lifting | |
Overall dimensions(L*W*H) | 8275x2500x3450 | |
About us:Shandong heavy truck and machinery Co., Ltd was established in 2017 in Jinan, China. We are professional supplier for Chinese brand heavy truck and construction machinery as well as spare parts. Sinotruk, Shacman, Beiben, CAMC, SEM, Foton, Weichai, liugong, Zhongtong, Yutong etc all fall in the scope of our business. Meanwhile, we have our own brand wheel loader and backhoe(with CE certificafte) etc, made by our own factory HOMONS MACHINERY LIMITED.
With good communication and services, our company has exported our products to Nigeria, Angola, Ghana, Libya, Cameroon, Guinea, Congo, Mali, Tanzania, Ethiopia, Algeria, Sudan, Egypt and other African countries; Peru, Chile, Venezuela, Colombia, Brazil and Argentina in South America; Ukraine, Russia, Tajikistan, Kazakhstan, Thailand, Philippines, Malaysia, Indonesia, Pakistan, Brunei and Bangladesh in Asia and other countries and regions.
Our company will adhere to the service concept of quality first, service first, and customer first, will provide our customers with the highest quality products and services. At the same time, customers are welcome to call, write to inquire about prices, and visit.
