Model NO.
T10-C
Voltage
72V
Controller
12 Tubes
Headlight
LED
Gradient
30 Degrees
Capacity
150kg
Suspension
Hydraulic Shock Absorber
Front Brake
Disc Brake
Rear Brake
Disc Brake
20gp Capacity
24 Units
40gp Capacity
48 Units
Transport Package
Shipped in 1 Piece
Specification
2320*720*1330mm
Trademark
OEM
Origin
Qingdao China
HS Code
8711600090
Production Capacity
5000 Units/ Month
After-sales Service:
6 Months
Warranty:
6 Months
Frame Material:
Steel
Tire Size:
14inch
Power:
8000W
Certification:
EEC
| Electric bicycle Model: | T10-C | Battery Model: | 72V60AH (Lithium) |
| Dimension: | 2320*720*1330mm | Battery Weight : | 20KG |
| Wheel Base: | 1560mm | Charging Time: | 6-8 Hours |
| Ground Clearance: | 15mm | Charging Source : | 84V 20A |
| Vehicle Weight: | 175KG | Maximum Speed : | 75~85 KM/H |
| Maximum Load: | 150KG | Mileage range: | 80~85KM (43KM/H) |
| Motor Type: | 72V45H5000W | Anti-theft System : | None |
| Low voltage protection value: | 63±1V | Braking System : | All Disc Brake |
| High voltage protection value : | 90±1V | Front Absorber : | φ33 Hydraulic Damping |
| Controller Model: | 72V450 | Back Absorber : | φ32 Hydraulic Damping |
| Panel Board: | 72V LCD | Front Tire Size : | 120/80-14 |
| Colors Available: | Red/Green/Silver/Black | Back Tire Size: | 140/60-13 |
| Container loading : | 20'GP :14 pcs | Climbing angel : | 20° |
| 40'HQ :32pcs | MOQ: | 14 pcs |
